Sterling Plastics
Founded by George and Mary Staab of Mountainside N.J., they purchased Acu-Rule Mfg. on June 25, 1968. Sterling operated in Mt. Olive for about a year and then moved the plant equipment to Union, New Jersey, then settling in Mountainside, New Jersey. Sterling Plastics was purchased and became a division of Borden Chemical in 1970. Slide rules were produced as late as 1972. Most models use the same mold, but vary at time by the color of the text or plastic slide or stock.
KEEP ISRM FREE!
584 587



Sterling 538 Pocket Slide Rule (Folded Film Type)

REF


B Potratz Collection
Sterling 538 Pocket Slide Rule (Folded Film Type)
Made in USA probably by C-Thru for Borden Chemical/ Sterling Plastics, Mountainside, NJ.
Note: Instructions printed on paper sleeve, typical of C-Thru slide rules
Front Scale: 6 in || A [ B, CI, C ] D ||15cm
Slide: Back: Decimal Equivalents
Archive


Sterling 584 white - First 2 bridge version with model number

ISRM 14.01.10.70
Sterling 584 white - First 2 bridge version with model number
Made in USA - Mountainside, NJ.
Note: First version off of the injection mold with model number imprinted in upper left stock, with early style stock construction having 2 bridges. Later versions removed the model number from the mold for future variances, but it still shows in instructions.
Front Scale
A [ B, CI, C ] D, K
Back Slide (flip to use)
[ S, L, T ]
Gift of the Bill Wehrend Collection, Palo Alto, California.
10" Instructions (4.4MB PDF)


Sterling 584 white - Second 2 bridge version with model number removed

ISRM 14.01.10.71
Sterling 584 white - Second Version with model number removed
Made in USA - Mountainside, NJ.
Note: Second version off of the injection mold with model number removed off of upper left stock and replaced with "Precision", with early style stock construction having 2 bridges. Model number still shows in instructions. Now different model numbers can be assigned to models have different colors of plastic or text.
Front Scale
A [ B, CI, C ] D, K
Back Slide (flip to use)
[ S, L, T ]
Gift of the Bill Wehrend Collection, Palo Alto, California.
10" Instructions (4.4MB PDF)


Sterling 589 white (red text on slide) - Early Version

ISRM 13.09.14.01
Sterling 589 white (red text on slide) - Early Version
Made in USA - Mountainside, NJ.
Note early style stock construction with only 2 bridges
Front Scale
A [ B, CI, C ] D, K
Back Slide (flip to use)
[ S, L, T ]


Sterling 684 white

ISRM 05.01.04.01
Sterling 684 white - 1968
Made in USA - Mountainside, NJ.
Front Scale
A [ B, CI, C ] D, K
Back Slide (flip to use)
[ S, L, T ]
Note: this is the transition from 2 bridges holding the stator together to 5 bridges. Evidently the first design was not reliable and the Sterling engineers modified the standard tooling to strengthen the stock. This was not intirely foolproof, as is evident from the 684 below, which belonged to the ISRM Curator's father.


Sterling 684 Slide Rule

ISRM 06.01.24.01


Leslie Konshak USAF SMSgt,
Retirement Ceremony (1958)

Sterling 684 white (Later Version)
Made in USA - Mountainside, NJ.
Note late style stock construction with 5 bridges
Front Scale
A [ B, CI, C ] D, K
Back Slide (flip to use)
[ S, L, T ]
Donated by Susan E. Konshak (1919-2003) and Leslie (Les) Konshak (1914-2010)
Mike Konshak, the ISRM Curator writes about his parent's slide rule: "Like most things Dad and Mom had, it was not elegant, always practical, and in this case is one of the least expensive out there. Yes, it's a Sterling 684 which many collectors wouldn't even give a second glance. Sometime along the way the plastic slide rule broke and rather than toss it away, Dad (or Mom) epoxied it back together and it was given a new life. Eat it up, wear it out, do with or do without. Les spent 20 years in the USAF retiring as a Senior Master Sergeant in 1959. He was an original founder of the The Retired Enlisted (Men's) Association (TREA) first charter in Colorado Springs, He spent 10 years working at Ampex Corp. in Colordao Springs and retired with a small pension. He and Susan (ne Garrard) spent their last years living in Tucson, Arizona Dad passed on in 2010 at age 93. Mom passed on in 2003 at 84. They are both buried at Fort Logan National Cemetary in Colorado. They had 4 children, 7 grandkids and as of 2011, 5 great grandchildren"


Sterling 587

ISRM 11.08.16.01

Finley Carlyle Pearce in 1973
Finley Carlyle Pearce (1915-1998) worked as a pressure vessel inspector for the State of California where he lived in Yorba Linda, Calif. for 29 years. Mr. Pearce retired from Shell Chemical after 30 years as a chemical engineer and safety officer. He was an active member of the LDS Church, and served as a bishop, stake president and patriarch. He was also very active and supportive of the Boy Scouts of America. He and his wife Orba had five sons and two daughters.
Sterling 587 - Closed Simplex
Made in USA - Mountainside, NJ.
Front Scale: A [ B, CI, C ] D, K
Back Slide (flip over to use): [ S, L, T ]
Donated by Ron Pierce of Littleton, Colorado
Ron Pearce describes the slide rule that belonged to his father, Finley Pearce: "He was a chemical engineer who worked primarily for Shell Chemical. The personal attachment for me is that as far as I know most of my siblings, including myself, literally cut our teeth on the slide rule case that held this slide rule. The case is gone, but the rule remains." "In another slide rule story, I recall being called to the president's office at Southern Pacific Transportation (railroad). The president was Denman McNear who was himself an engineer. I was a cost analyst at the time and used an HP financial calculator to perform my analysis. Mr, McNear would check our figures using his pocket slide rule which was about the same size as my father's slide rule."


P019 Sterling 587 Promotional
Sterling 587 - Promotional
Made in USA - Mountainside, NJ.
Front Scale
A [ B, CI, C ] D, K
Back Slide (flip to use)
[ S, L, T ]
Back Adv: LightninMixers and Agitators, Mixing Equipment Co., Inc., Rochester, NY
Original owner: Michael P. Taylor, retired Director Dow Chemical. Graduated Univ of Houston, TX. Taught at TAMU and UH. Designed/Built the Houston Dow Center &Dow Chemical plant in Toronto.


Sterling 587 Promotional (ESNA)

ISRM 11.11.11.02

5" Instructions
(4.4MB PDF)
Sterling 587 - Promotional (ESNA)
Made in USA - Mountainside, NJ.
Front Scale
A [ B, CI, C ] D, K
Back Slide (flip to use)
[ S, L, T ]
Back Adv: Amerace ESNA Corp. Union, New Jersey
Donated by David Sweetman


Sterling 689 green slider

ISRM 13.06.25.10


Norma Tanner with Pickett Teaching slide rule
Sterling 689 green slider
Made in USA - Mountainside, NJ.
Front Scale: A [ B, CI, C ] D, K
Back Slide: [ S, L, T ]
Gifted by Norma Tanner of Libertyville, Illinois
Norma has been a participant of the ISRM Slide Rule Loaner Program. In addition, she had her own collection that she loaned out to students. This one is part of the collection sent to ISRM. Norma writes: "After teaching math and/or science for 24 years, I am now enjoying retired life. Having been educated at MIchigan State University during a time when using a slide rule was the only technology available for advanced calculations, I decided to create a unit of study for my students that would introduce them to the slide rule. My goals were for students to strengthen their ability to estimate and use scientific notation, as well as to discover the historic significance of the slide rule. While it was hard for them to put aside their electronic calculators, they were fascinated, engaged, and thrilled when they could multiply 2 x 3 and actually get 6 instead of 5.9. In the end my students were happy to be reunited with their calculators, but had a new appreciation for the value of estimating, scientific notation, and accuracy in measurement. Goals met! "


Sterling 689 green stock, white slide

ISRM 13.09.14.02
Sterling 689 green stock, white slide
Made in USA - Mountainside, NJ.
Front Scale
A [ B, CI, C ] D, K
Back Slide
[ S, L, T ]


Sterling 589 Senior red txt slide

ISRM 11.11.11.04
Sterling 589 Senior red txt slide - Closed Simplex
Made in USA - Mountainside, NJ.
Front Scale: A [ B, CI, C ] D, K
Back Slide (flip to use)
[ S, L, T ]
Original Owner: Walter T.Irwin, 1923 Houston Dr., Las Vegas, Nevada.
Donated by David Sweetman


Sterling 594 Decimal Trig Log-Log ©1965

ISRM 12.06.24.56
Sterling 594 Decimal Trig Log-Log ©1965
Made in USA - Mountainside, NJ.
Front Scale: LL01, K, A [ B, T<45, T>45, ST, S ] D, DI, LL1
Back Scale: LL02, LL03, DF, [ CF, CIF, L, CI, C ] D, LL3, LL2
Note slight differences in scale label fonts.
Donated by the Huang Collection.
The donor, who prefers to remain anonymous, obtained a B.S. degree in Physics from Taiwan's National Tsing Hua University in 1971. His love for computation has encouraged him to build a collection of slide rules, HP and TI calculators, as well as abaci, many displayed at ISRM.


S222 Sterling (594) Decimal Trig Log Log ©1965
Sterling (594) Decimal Trig Log Log ©1965
Made in USA - Mountainside, NJ. - Tan/Brown color
Front Scale: LL01, K, A [ B, T<45, T>45, ST, S ] D, DI, LL1
Back Scale: LL02, LL03, DF, [ CF, CIF, L, CI, C ] D, LL3, LL2
Note: Missing Model number but has copyright date


Sterling 594 Decimal Trig Log-Log (1972)

ISRM 14.10.10.11
Sterling 594 Decimal Trig Log-Log (1972)
Made in USA - Sterling, Mountainside, NJ.
Front Scale: LL01, K, A [ B, T<45, T>45, ST, S ] D, DI, LL1
Back Scale: LL02, LL03, DF, [ CF, CIF, L, CI, C ] D, LL3, LL2
Note: Missing Model number and copyright date (look at the 594s)
Gift of Edward Wright, Odenton, Maryland.


Sterling 694 Decimal Trig Log-Log (1972)

ISRM 11.11.11.03
Sterling 694 Decimal Trig Log-Log (1972)
Made in USA - Borden/Sterling, Mountainside, NJ.
Front Scale: LL01, K, A [ B, T<45, T>45, ST, S ] D, DI, LL1
Back Scale: LL02, LL03, DF, [ CF, CIF, L, CI, C ] D, LL3, LL2
Note: Missing Model number and copyright date (look at the 594s). It appears when Borden bought Sterling they changed the model number of the 594, or the number refers to the retail packaging.
Donated by David Sweetman


Sterling 651 Metric Converter

ISRM 12.07.18.01
Sterling 651 Metric Converter - Green colors
Made in USA - Mountainside, NJ. - 1972
Front Scale: Volume, Weight, Liquid
Back Slide (flip to use): Linear distances and Area
Note: White slide, Green Stock
Owned by Ward Anthony, Littleton, Colorado. Donated by his son Russell Anthony, Lafayette, CO. Ward B. Anthony ( -2012) was an aerospace engineer at Martin Marietta in Littleton, Colorado and worked on many of the launch systems. He used this slide rule in his profession. He built his own home in Morrison, CO.


S148 Sterling (651) Metric Converter
Sterling (651) Metric Converter
Made in USA - Mountainside, NJ.
Front Scale: Volume, Weight, Liquid
Back Slide (flip to use): Linear distances and Area
Note: White slide, Yellow Stock
Manual Donated by Albert Klumpp, Arlington Heights, Illinois 213Kb PDF


Sterling 651 Metric Converter

ISRM 13.01.08.01
Sterling 651 Metric Converter - Inverted colors
Made in USA - Mountainside, NJ. - 1972
Front Scale: Volume, Weight, Liquid
Back Slide (flip to use): Linear distances and Area
Note: Yellow slide, White Stock
Donated by Susanne Petersson of Park Ridge, Illinos
This slide rule was owned by Susanne Petersson's brother, Andeas, who recalls that his grandmother, gave this to him along with a set of drafting tools. Another donation of a Reiss slide rule is in the Germany/DDR gallery
In Family photo on left: Grandmother, Susanne, sister Sylvia, brother Andreas


P168 Sterling Pocket Metric Converter

Instructions 213Kb PDF
Sterling Pocket Metric Converter
Made in USA - Mountainside, NJ.
Front Scale: Volume, Weight, Liquid, Linear distances and Area
Back Slide (flip to use): Fahrenheit-Celsius Conversion
Instructions Donated by Albert Klumpp, Arlington Heights, Illinois


ISRM Sterling 585 Deluxe (Black Text slide - open back)
ISRM 11.11.11.01
Sterling 585 Deluxe (Black Text slide - open back)
Made in USA - Mountainside, NJ.
Note Open Back
Front Scale: 10in 1/16 // A [ B, CI, C ] D, K \\ 10in .050
Back Slide (flip to use): [ S, L, T ]
Donated by David Sweetman


Sterling 585 Deluxe 10" (red text slide - open back)

ISRM 12.06.24.63
Sterling 585 Deluxe 10" (red text slide - open back)
Made in USA - Mountainside, NJ.
Front Scale:
10in 1/16 // A [ B, CI, C ] D, K \\ 10in .050
Back Slide (flip to use): [ S, L, T ]
Donated by Huang Collection


Sterling (685) red text slide - solid back

ISRM 11.11.10.01
Sterling (685) red text slide
Made in USA - Mountainside, NJ.
Front Scale:
10in 1/16 // A [ B, CI, C ] D, K \\ 10in .050
Back Slide (flip to use): [ S, L, T ]


S153 Sterling 685 green slide
Sterling 685 green slide - 1968
Made in USA - Mountainside, NJ.
Front Scale: 10in 1/16 // A [ B, CI, C ] D, K \\ 10in .050
Back Slide (flip to use): [ S, L, T ]


S232 Sterling 685 green-stock
Sterling 685 green stock - 1968
Made in USA - Mountainside, NJ.
Front Scale: 10in 1/16 // A [ B, CI, C ] D, K \\ 10in .050
Back Slide (flip to use): [ S, L, T ]


Sterling 689 Mannheim Trig (1972)
Sterling 689 Mannheim Trig - green stock, white slider
Made in USA - Borden Chemical/ Sterling Plastics, Mountainside, NJ.
Front Scale: A [ B, CI, C ] D, K
Back Slide (flip to use): [ S, L, T ]
Archive - Not in collection


Sterling 565 4-Digit Dial-A-Matic Adding Machine

ISRM 04.10.09.01
Sterling 565 4-Digit Dial-A-Matic Automatic Adding Machine
Made in USA by Sterling Plastics, Mountainside, NJ.
Front: Four dials - Thousands, Hundreds, Tens and Units


Sterling 566 4-Digit Dial-A-Matic Adding Machine and Pencil Box

REF
Sterling 566 4-Digit Dial-A-Matic Adding Machine and Pencil Box
Made in USA by Sterling Plastics, Mountainside, NJ.
Note: This unit slits in two and rotates about the rivet to get access to the pencil box.
Front: Four dials - Thousands, Hundreds, Tens and Units
Archive - ebay photo


Sterling 567 5-Digit Dial-A-Matic Adding Machine

REF
Sterling 567 5-Digit Dial-A-Matic Automatic Adding Machine
Made in USA by Sterling Plastics, Mountainside, NJ.
Front: Five dials - Ten Thousands,Thousands, Hundreds, Tens and Units
Archive - David Riches collection, UK


Sterling 568 6-Digit Dial-A-Matic Adding Machine

ISRM 14.09.08.07
Sterling 568 6-Digit Dial-A-Matic Automatic Adding Machine
Made in USA by Sterling Plastics, Mountainside, NJ.
Front: Six dials - 100 Thousand, Ten Thousands,Thousands, Hundreds, Tens and Units
Gift of Edward Wright, Odenton, Maryland
