Miscellaneous Europe

Ahrend



ISRM Ahrend Sun Hemmi P280 (Ahrend 435660)		 Ahrend Sun Hemmi P280 (Ahrend 435660)
Made in Japan by Hemmi for Dutch Company Ahrend - c1973
Front Scale
T Cot, K, A [ B, CI, C ] D, L, S Cos, ST ST
Back Scale
[ LL1, LL2, LL3 ]
Donated by David Hecht, Alexandria, VA


REF Ahrend Hemmi P281 		Ahrend Hemmi P281 - Open simplex
Made in Japan by Sun Hemmi for Dutch Company Ahrend
Front Scale
T Cot, K, A [ B, CI, C ] D, L, S Cos, ST
Back Slider
[ LL1, LL2, LL3]
Archive - Herman van Herwijnen's SR Catalogue


REF Ahrend Hemmi P283 		Ahrend Hemmi P283 - Open simplex
Made in Japan by Sun Hemmi for Dutch Company Ahrend
Front Scale
K, A [ B, CI, C ] D, L, T Cot, S Cos
Back Slider
[ LL1, LL2, LL3]
Archive - Herman van Herwijnen's SR Catalogue


REF Ahrend Hemmi 642T 		Ahrend Hemmi 642T - Open simplex
Made in Japan by Sun Hemmi for Dutch Company Ahrend
Front Scale
27cm // K, A [ B, BI, CI, C ] D, DI, L
Back Slider
[ T2, T1, ST, S]
Archive - Herman van Herwijnen's SR Catalogue


REF Ahrend 649 Schola 		Ahrend 649 Schola
Made in Germany for Dutch Company Ahrend
Front Scale
A [ B, C ] D
Archive - Herman van Herwijnen's SR Catalogue


REF Ahrend 652 Rietz 		Ahrend 652 Rietz
Made in Germany for Dutch Company Ahrend
Front Scale
26cm // A [ B, C ] D || 10in
Back Slider
[S, ST, T]
Archive - Herman van Herwijnen's SR Catalogue


REF Ahrend 654 Electro 		Ahrend 654 Electro
Made in Germany for Dutch Company Ahrend
Front Scale: 26cm // A [ B, C ] D || 10in
Well: Dynamo, Volt
Back Slider: [S, ST, T]
Archive - Herman van Herwijnen's SR Catalogue


REF Ahrend 690 Electro 		Ahrend 690 Electro
Made in Germany (same as Aristo 89) for Dutch Company Ahrend
Front Scale: 13cm // K, A [ B, CI, C ] D, L
Back Slider: [S, ST, T]
Archive - Herman van Herwijnen's SR Catalogue


REF Ahrend 696 		Ahrend 654
Made in Germany (same as Aristo 915) for Dutch Company Ahrend
Front Scale: 28cm // K, A [ B, BI, CI, C ] D, LL3, LL2, D/M, V
Back Slider: [S, ST, L, T]
Archive - Herman van Herwijnen's SR Catalogue


REF Ahrend 701 Technica 		Ahrend 701 Technica
Made in Germany (same as Aristo 929) for Dutch Company Ahrend
Front Scale: 25cm, P, K, A [ S, T, ST, S ] D, DI, 10in
Back Scale: K, DF [CF, CIF, CI, C ] D, L
Archive - Herman van Herwijnen's SR Catalogue


REF Ahrend Construction Disk 		Ahrend Construction Disk
Made in Netherlands by Ahrend
Archive - Herman van Herwijnen's SR Catalogue



REF Diwa Log Log 101 		Diwa Log Log 101 - c1948
Made in Denmark - Wood w/Plastic laminate
Front Scale
10in // LL2, A [ B, CI, C ] D, LL3 || K
Back Scale (window)
[ S, S&T, T ]
Back: Equivalents
Cursor: 3 hairlines, extended to side (for K scale)
wood case


REF Diwa 201 Technical 		Diwa 201 Technical - c1955
Made in Denmark - Wood w/Plastic laminate
Front Scale
25cm // K, A [ B, CI, C ] D, L
Back Scale (window)
[ S, S&T, T ]
Back: Equivalents
Cursor: 3 hairlines
Archive Herman van Herwijnen's SR Catalogue


S244 Diwa Rietz-301 		Diwa Rietz-301
Made in Denmark - Wood w/Plastic laminate
Front Scale
25cm/10in // K, A [ B, CI, C ] D, L
Back Scale (window)
[ S, S&T, T ]
Back: Equivalents
Cursor: 3 hairlines


S315 Diwa 311 Electro 		Diwa 311 Electro - Closed simplex
Made in Denmark - Wood w/Plastic laminate
Front Scale
25cm/10in // Dynamo/Motor, K, A(kW) [ B(hp), CI, C ] D, Volt, tg ctg, cin cos
Back Scale (window)
[LL1, LL2, LL3 ]
Back: Equivalents
Cursor: 4 hairlines


S283 Diwa Rietz-Ideal No. 1 		Diwa Rietz-Ideal No. 1
Made in Denmark - All Plastic
Front Scale
25cm/10in // L, K, A [ B, CI, C ] D, S, ST, T
Back Scale: Blank
Cursor: 3 hairlines
Original Owner: Hans Christiansen/Rinngade Strauss/Netherlands


ISRM Diwa 601 		Diwa 601
Made in Denmark - All Plastic
Front Scale
5in // K, A [ B, CI, C ] D, L
Back Scale: [ S, S&T, T ]
Cursor: 3 hairlines
Donated by David Hecht, Alexandria, Virginia
Back Advertising: Maxon Premix Burner Co. Muncie, Indiana


REF Diwa 710 Teknilog 		Diwa 710 Teknilog - Duplex
Made in Denmark
Front Scale
LL00, ST, T, DF [ CF, CIF, CI, C ] D, P, S, LL0
Back Scale
LL01, LL02, LL03, A [ B, L, K, C ] D, LL3, LL2, LL1
Cursor: 5 hairlines
Archive - Marion Moon Collection


S336 Diwa 720 Polylog 		Diwa 720 Polylog - Duplex
Made in Denmark
Front Scale
LL00, L, K, A [ B, S, ST, T, C ] D, DI, P, LL0
Back Scale
LL01, LL02, LL03, DF [ CF, CIF, CI, C ] D, LL3, LL2, LL1
Cursor: 5 hairlines


ISRM Diwa 911 		Diwa 911
Made in Denmark (closely resembles Dietzgen construction)
Front Scale
LL0, LL00, A [ B, T Cot, ST, S Cos, C ] D, DI, K
Back Scale
L, LL1, DF [ CF, CIF, CI, C ] D, LL3, LL2
Donated by David Hecht, Alexandria, VA


P106 Eco-Bra 1270 		Eco-Bra 1270 Pocket - Closed simplex
Made in Germany - c1940 - all aluminum
Front Scale (unmarked)
14cm // A [ B, C ] D
Back Adv: Aluminum Company of Canada


REF Eco-Bra Rietz R141 		Eco-Bra Rietz R141
Made in Germany - c1960 - Plastic
Front Scale
13cm // A [ B, CI, C ] D, K
Archive - W. Girbardt (Univ Greifswald, Germany) Collection


P257 Eco-Bra Darmstadt R143 		Eco-Bra Rietz R141
Made in Germany - c1960 - Plastic
Front Scale
13cm // LL2, LL3, A [ B, CI, C ] D, K, LL1
Back Scale
P, T Cot, L, S Cos
Back Adv: INA-Nadellager


P267 Eco-Bra nr1461 System Rietz 		Ecobra nr1461 System Rietz
Made in Germany - c1950 - Painted aluminum
Front Scale
K, A [ B, R, C ] D, lg
Back Scale
5in [ sin, tg ]
Original location: Netherlands


REF Eco-Bra 154 Cosmos 		Eco-Bra 154 Cosmos
Made in Germany - Plastic - Identical to Hope 530
Front Scale (extended)
LL01, LL02, LL03, A [ B, L, K, C ] D, LL3, Ll2, LL1
Back Scale
T Cot, ST ST, DF [ CF, CIF, CI, C ] D, P, S Cos
Archive - Rod Lovette Collection


REF Eco-Bra 1500 		Eco-Bra 1500
Made in Germany - c1940 - all aluminum
Front Scale
25cm // K, A [ B, CI, C ] D, L
Archive - W. Girbardt (Univ Greifswald, Germany)Collection


ISRM Eco-Bra 1611 Darmstadt Special 		Eco-Bra 1611 Darmstadt Special
Made in Germany - Painted Aluminum
Front Scale (extended)
T Cot, S Cos, DF [ CF, CI, C ] D, P
Back Scale
K, A [ B, Lg, C ] LL3, LL2, LL1
Donated by David Hecht, Alexandria, VA


REF Eco-Bra 1711 Cosmos 		Eco-Bra 1711 Cosmos
Made in Germany - Aluminum
Front Scale (extended)
LL02, LL03, DF [ CF, CIF, L, CI, C ] D, LL3, Ll2,
Back Scale
LL01, K, A [ B, T<45 Cot, T>45 Cot, ST, S Cos ] D, P, S , LL1
Archive - Rod Lovette Collection

Fedra



S572 Fedra Log Log 		S572_Fedra Log Log - Closed duplex - DC Aug1968
Made in East Germany possibly by Veb Mantissa
Front Scale
K, A [ B, CI, C ] D, L
Back Scale
27cm, S, ST, T, LL1, LL2, LL3, 10.75Inch
Back Slide: [Greek Alphabet]
Same as Staedtler Mars 544-52 Log Log
Donated by Seth Balish
Note: This model of slide rule is available in the Slide Rule Loaner Program

Friedmann



P182 Friedmann 4in Pocket Mannheim 		Friedmann 4in Pocket Mannheim
Made in Germany
Front Scale
A [ B, CI, C ] D, K
Back Slider
[ S, L, T ]

Gamma



P014 Gamma Pocket 		Gamma Pocket - Closed simplex
Made in Hungary
Front Scale (unmarked)
13cm // K, A [ B, CI, C ] D, L
Back Slider
[ S, S&T, T ]

Hono-Rietz



REF Hono-Rietz Jap.125 		Hono-Rietz Jap.125 - Closed simplex
Possibly made in France by Graphoplex - Sold in Italy
(compare cursor design and unconventional scale labels)
Front Scale
13cm // B3(K), S, B2(A) [ b2(B), a(CI), b(C) ] B(D), T, L
Back TBD
Archive - Scarpaz collection (Italy)


REF Hono-Rietz Jap.125 		Hono-Rietz Jap.125 - Closed simplex
Possibly made in France by Graphoplex - Sold in Italy
(compare cursor design and unconventional scale labels)
Front Scale
13cm // B3(K), S, B2(A) [ b2(B), a(CI), b(C) ] B(D), T, L
Back Adv: Dalmar S.p.a. - Italian hydraulic hose/gasket manufacturer
Archive - G. Breda collection (Italy)

H-H Universum



P255 H-H Universum System Rietz 		H-H Universum System Rietz
Made in Germany - c1930
Front Scale - Extended
22cm // A [ B, CI, C ] D, L \\ 22cm
Back Scale: [ S, T ]
Multilined Cursor
Back: Conversions (German)

IWA - Ingenieurerbüro für wirtschafliches Arbeiten

IWA is most famous for its slide charts. These in this gallery more resemble generic slide rules.


REF IWA 0272 Electronic 		IWA 0272 Electronic
Made in Germany for Dutch firm De Muiderkring N.V.- c1963
Front Scale - Extended
Lambda, Omega, f [ C, L, RC ] L/C, RL
Back Scale:
K, Sin Cos, A [ B, CI, C ] D, Ln, 25cm
Multilined Cursor
Archive - scan by Tom Cattrall


REF IWA 01206 Machining - Roughness Slide Rule for Turning 		IWA 01206 Machining - Roughness Slide Rule for Turning
Made in Germany - c1971
Front Scale - Extended
26 cm // r (4 scales), feed [ V in m.min ] Ra, Rt \\ 10.2 inches
Back: Direction in English and German
Archive - scan by Jim Cerney

Joe Klawun



P258 Joe Klawun No. 666/T 		Joe Klawun No. 666/T - Closed simplex
Made in Germany (identical to Nestler 11-ZM) Feinmessinstitut Berlin Charlottenburg 5
Front Scale (extended)
13cm // A [ B, C ] D
Back: Blank

Karl-Wess



P125 Karl Wess 		Karl Wess - Closed simplex
Made in Germany(?Aristo)
Front Scale
13cm // A [ B, CI, C ] D, K || 5inch
Back Slider: [ S, L, T ]

Kent



S061 Kent 7153LL 		Kent 7153LL - Open simplex
Made in Japan, Uchida Yoko Co., for Dutch Company Kent
Front Scale
L, K, A [ B, CI, C ] D, S, ST, T
Back Scale
25cm [ S, LL2, LL3] 10 inch


S433 Kent 7300LL 		Kent 7300LL - Open simplex
Made in Japan, Uchida Yoko Co., for Dutch Company Kent
Front Scale
T Cot, K, A [ B, CI, C ] D, S Cos, ST, L
Back Scale
[ LL1, LL2, LL3]

Kern & Co. Aarau, Suisse



REF Kern Stadia Surveyor's Slide Rule 		Kern Stadia Surveyor's Slide Rule
Made in Switzerland by Kern & Co. Aarau, Suisse
Closed body - Steel stock and cursor
Front Scale
D, D [ X, Sin-Cos, TG. ] F-R
Cursor: 0-100 veneer scale
Archive - Tom dilatush Collection


REF Kern Stadia Surveyor's Slide Rule 		Kern Stadia Surveyor's Slide Rule
Made in Switzerland by Kern & Co. Aarau, Suisse
Closed body - Aluminum stock and cursor
Front Scale
Dist. Feet, Dist Miles [ Vertical Angles ] Diff. Elev. Part, Correction in Feet For Curvature.
Archive - David Ingram Collection -  www.surveyhistory.org

Loga Daemon-Schmid, Zurich, Switzerland



REF Daemen-Schmid (Loga) 24 meter cylindrical 		Daemen-Schmid (Loga) 24 meter cylindrical
Made in Switzerland by Daemon-Schmid 1915-1920
Paper faced aluminum drum
CD (100-1000) scales divided into 60 segments for a total length of 24 meter
Archive - Ed Chamberlain Collection
Galai Photo.


Ref Loga Calculator (Daemen-Schmid) 15 meter cylindrical 		Loga Calculator (Daemen-Schmid) 15 meter cylindrical
Made in Switzerland by Daemon-Schmid


ISRM Loga (Daemen-Schmid) 7.5 meter cylindrical 		Loga (Daemen-Schmid) 7.5 meter cylindrical
Made in Switzerland by Daemon-Schmid c1930


REF Loga (Daemen-Schmid) 7.5 meter cylindrical 		Daemen-Schmid (Loga) 7.5 meter cylindrical
Made in Switzerland by Daemon-Schmid c1930
Archive - Ed Chamberlain Collection


ISRM Loga (Daemen-Schmid) 2.5 meter cylindrical 		Daemen-Schmid (Loga) 2.5 meter cylindrical
Made in Switzerland by Daemon-Schmid c1930
Archive - Herman's Slide Rule Catalogue


REF Loga Slide Rule 		Loga Slide Rule
Made in Switzerland - Paper and metal backing
Front Scale:
Zz(K1), A [ B, R, C ] D, Zz(K2)
Back Scale:
A [ B, R ] C, Currency Conversions
Archive Herman van Herwijnen's Slide Rule Catalogue


REF Loga Pocket Slide Rule 		Loga Pocket Slide Rule
Made in Switzerland - Paper and metal backing
Front Scale:
K, A [ B, R, C ] D, Log
Back Scale:
A [ B, R ] C, Currency Conversions
Archive Herman van Herwijnen's Slide Rule Catalogue

Logarecta Déposé



REF Logarecta Déposé - Malta Logarithmic Scales 		Logarecta Déposé - Malta Logarithmic Scales
Made in Belgium
Front Scale:

BackScale: Trig scales
Archive - Herman van Herwijnen's SR Catalogue

Logarex



ISRM Logarex 27103 Rietz (early) 		Logarex 27103 Rietz (early)
Made in Czechoslovakia - Bohemia Works
Front Scale
K, A [ B, CI, C ] D, log
Back Scale
4in, Ωmm2/m [ S, T] Constants, 10cm
Cursor: 4 hairlines: q, kW, d, PS
Donated by David Hecht, Alexandria, VA


P183 Logarex 27103 Rietz 		Logarex 27103 Rietz
Made in Czechoslovakia - Bohemia Works
Front Scale
K, A [ B, CI, C ] D, L
Back Scale
4in, Ωmm2/m [ S, T] Constants, 10cm
Cursor: 4 hairlines: q, kW, d, PS


P171 Logarex 27204-II Rietz 		Logarex 27204-II Rietz
Made in Czechoslovakia - Bohemia Works - Date 7-65
Front Scale
K, A [ B, CI, C ] D, L
Back Scale
12.5cm [ S, S-T, T ] 5in, Equivalents
Cursor: 3 hairlines


P039 Logarex 27205 Exponent 		Logarex 27205 Exponent - Duplex
Made in Czechoslovakia - Bohemia Works Toisen DOR
Front Scale (extended scales)
L, P, K, A [ B, CI, C ] D, tg, sin, s-t
Back Scale
LL1, LL2, LL3, DF [ CF, CIF, CI, C] D, LL00, LL01, LL02
Cursor: 3 hairlines: PS, KW, q, d


P115 Logarex 27302 		Logarex 27302
Made in Czechoslovakia - Bohemia Works
Front Scale
15cm, P, K, A [ B, L, CI, C ] D, S, T
Back Scale
40mm(1:25) [ LL1, LL2, LL3 ] Table of Constants
Cursor: 4 hairlines


ISRM Logarex 27401-X Rietz 		Logarex 27401-X Rietz
Made in Czechoslovakia - Bohemia Works
Front Scale (extended scales)
K, A [ B, CI, C ] D, L
Back Scale
Equivalents [ S, ST, T] Equivalents
Multiple hairline cursor: q, PS, KW, d
Donated by David Hecht, Alexandria, VA


S569 Logarex 27403-X Darmstadt 		Logarex 27403-X Darmstadt
Made in Czechoslovakia - Bohemia Works
Front Scale (extended scales)
L, P, K, A [ B, CI, C ] D, Sin, Tg, S-T
Back Scale
Equivalents [ LL1, LL2, LL3 ] Equivalents
Multiple hairline cursor: q, PS, KW, d
Original Location: Russia


S339 Logarex 27403-II Darmstadt 		Logarex 27403-II Darmstadt
Made in Czechoslovakia - Bohemia Works
Front Scale (extended scales)
25cm, L, P, K, A [ B, CI, C ] D, Sin, Tg, S-T || 1:25 7m
Back Scale
[ LL1, LL2, LL3 ]
Cursor: 4 hairlines: q, kw, d, PS
Has Previous Owner's Monogram on back


REF Logarex 27602-II Exponent 		Logarex 27602-II Exponent - Open Duplex
Made in Czechoslovakia - Bohemia Works - Toisen DOR
Front Scale (extended scales)
L, P, K, A [ B, CI, C ] D, S, T, ST
Back Scale
LL1, LL2, LL3, DF [ CF, CIF, CI, C ] D, LL00, LL01, LL02
Cursor: 3 hairlines: PS, KW, q, d
Archive - Not in Collection

Meissner



REF Meissner KG Multi Pocket 		Meissner KG Multi Pocket (1974)
Made in DDR/Germany - Same factory as Veb Mantissa
Front Scale
13cm // ST, A, DF [ CF, CIF, CI, C ] D, P, S, T
Back Slider (unverified): [ LL1, LL2, LL3, L ]
Cursor: multiple hairlines
Archive - Gerhard Wenzel collection (Netherlands)


REF Meissner KG Mono Rietz 731-541 		Meissner KG Mono Rietz 731-541
Made in DDR/Germany - Same factory as Veb Mantissa
Front Scale
L, K, A[ B, CI, C ] D, S, T, ST
Back Slider (unverified): [ LL1, LL2, LL3, L ]
Archive - Courtesy of www.oldjurnal.narod.ru

Neolt-Bergamo



REF Neolt-Bergamo Rietz 25 		Neolt-Bergamo Rietz 25
Made in Italy
Front Scale
27cm // K, A[ B, CI, C ] D, L
Back Slider: [ S, S&T, T ]
Cursor: multiple hairlines
Archive Herman van Herwijnen's Slide Rule Catalogue


REF Neolt TS 10 		Neolt TS 10
Made in Italy
Front Scale
10cm // A[ B, C ] D
Archive Herman van Herwijnen's Slide Rule Catalogue

Norden



P060 Norden-SKF 		Norden-SKF
Made in Sweden
Front Scale
14cm // K, A [ B, CI, C ] D, L \\ sin cos
Back  Adv: SKF
Back Scale
[ Log, tg ctg, P ]

Reiss

Bad Liebenwerda, (East)Germany


P002 Reiss Pocket Simplex 		Reiss Simplex
Made in Germany - brushed aluminum
Front Scale
13 CM // A [ B, C ] D
Back Scale
[ Sin, Log, Tg ]


Reiss 3201 Rietz-Spezial 		Reiss 3201 Rietz-Spezial
Made in Germany - brushed aluminum
Front Scale
L, DF [ CF, CI, C ] D, DI
Back Scale (extended)
ST, T [ K, B, C ] S, P


REF Reiss 3209 Pocket Simplex 		Reiss 3209 Simplex (1972)
Made in Germany - brushed aluminum
Front Scale (extended)
13 CM // K, A [ B, C ] D, L
Back Scale (not verified):[ Sin, S&T, Tg ]
Archive - Gerhard Wenzel collection


REF Reiss 3214 Darmstadt-Record 		Reiss 3214 Darmstadt-Record
Made in Germany - Plastic
Front Scale (extended scales)
L, K, A [ B, CI, C ] D, LL1, LL2, LL3
Back Scale
P, S, ST, DF [ CF, CIF, CI, C ] D, T1, T2, DI
Cursor: 3 hairlines
Original owner: Sckerr Peter Schwerin
Photo contributed by Marion Moon


S198 Reiss 3236 Darmstadt 		Reiss 3236 Darmstadt - Duplex
Made in Germany - Plastic
Front Scale (extended scales)
K, A [ B, CI, C ] D, L
Back Scale
P, S [ LL1, LL2, ll3 ] T1, T2
Cursor: 3 hairlines


ISRM Reiss Rietz 		Reiss Rietz
Made in Germany - Plastic
Front Scale
13cm // K, A [ B, CI, C ] D, L
Back Scale
[ S, T]
Cursor: 3 hairlines
Donated by David Hecht, Alexandria, VA


ISRM Reiss Darmstadt DDR 		Reiss Darmstadt DDR - Duplex
Made in East Germany - Plastic
Front Scale
K, A DF [ CF, CIF, CI, C ] D, P, S, T
Back Scale
[ LL1, LL2, LL3, L]
Cursor: 4 hairlines
Donated by David Hecht, Alexandria, VA


Reiss Darmstadt DDR 		Reiss Darmstadt DDR
Made in East Germany - Brushed Aluminum
Front Scale
K, A [ B, CI, C ] D, L
Back Scale
Cos, Sin/Tg [ LL1, LL2, ll3 ] sin, tg
Cursor: 4 hairlines


S038 Reiss Rietz 		Reiss Rietz
Made in East Germany - Brushed Aluminum
Front Scale
K, A [ B, CI, C ] D, L
Back Slider
[ Sin, Arc, Tan ]
Cursor: 4 hairlines - PS, KW

Rista



S259 Rista Rietz 1 		Rista Rietz 1
Made in  Germany - Plastic
Front Scale
K, A [ B, CI, C ] D, L
Back Slider
[ S, S&T, T ]
Cursor: 4 hairlines

Seehase, Dr. Ing.

Design based on German patent DE727007, 4 September 1939 by Dr. Ing. Hans Seehase.


P015 Dr. Ing. Seehase Pocket		 Dr. Ing. Seehase Pocket - Advertising - c1950
Made in Germany
Front Scale
A [ B, C ] D
Back: Hardwick Hindle Inc. Resistors, USA


REF Dr. Ing. Seehase Pocket		 Dr. Ing. Seehase Pocket - Advertising - c1950
Made in Germany
Front Scale
A [ B, C ] D
Back Scale: 5inch [] 13cm Back: Automotive Products Company, London.
Archive - Herman's Slide Rule Catalogue


REF Dr. Ing. Seehase - Elektro Praktikus		 Dr. Ing. Seehase - Elektro Praktikus - c1950
Made in Germany - Alternating Current (power) Calculator
Front Scale
m [ A, V ][ qmm ] Cos (phase)
Back Scale:
qm [ Lx, Lp ][ Watt ] n (eta)
Note: two slides
Archive - Herman's Slide Rule Catalogue


REF Dr. Ing. Seehase - Träger-rechenstab		 Dr. Ing. Seehase - Träger-rechenstab - c1950
Made in Germany - Structural Calculator
Front Scale
cm [ m, cm ] Kg/m2
Back Slide:
[ m, (nomograph), cm ]
Back: Reference Tables, Nomographs
Archive - Herman's Slide Rule Catalogue


REF Dr. Ing. Seehase - Sonderrechenstab SR 704		 Dr. Ing. Seehase - Sonderrechenstab SR 704 - c1950
Made in Germany - Spring Design Calculator
Front Scale
Wire dia [ Radius of coil, Kg/cm2 ] P gramm (force)
Archive - Herman's Slide Rule Catalogue


REF Dr. Ing. Seehase - Sonderrechenstab SR 705		 Dr. Ing. Seehase - Sonderrechenstab SR 705 - c1950
Made in Germany - Spring Design Calculator
Front Scale
Number of coils [Wire dia, Radius of coil][stress, P (force) Kg/cm2 ] f (Travel) mm
Note: Two slides
Archive - Herman's Slide Rule Catalogue

Skala



REF Skala Pocket Simplex 		Skala Simplex (1973)
Made in Poland
Front Scale ()
15 CM // K, A [ B, CI, C ] D, L
Back Scale (not verified)
[ Sin, S&T, Tg ]
Archive - Gerhard Wenzel collection


REF Skala Electrical 		Skala Electrical
Made in Poland
Front Scale ()
Efficiency, Volt, L, P, K, A [ B, CI, C ] D, LL3, LL2, sin cos, tg ctg, S-T
Back Scale (unknown)
Archive - Prof. Dr. Jörn Luetjens collection



GFT Staedtler Mars 54401 Darmstadt 		Staedtler Mars 54401 Darmstadt - 1961
Made in Germany
Front Scale
10.5 // L, K, A [ B, CI, C ] D, P, S Cos, T Cot
Back Scale
Equivalents (english) [ LL1, LL2, LL3]
Donated by Russell Fox, Anchorgae, Alaska. Used by his father who purchased it in Germany 1961-1964. He worked as an Electrical Engineer with BPA in Portland, Oregon.


S093 Staedtler Mars 544LL 		Staedtler Mars 544LL - Open Simplex
Made in Germany
Front Scale
L, K, A [ B, CI, C ] D, S, ST, T
Back Slider
25cm [ S, LL1, LL2, LL3] 10 inch


REF Staedtler Mars 544-28 Log Log 		Staedtler Mars 544-28 Log Log - dc969 ( Sep 1969)
Made in Germany by Nestler (same as Nestler 0292)
Front Scale
P, S, T1, T2, A [ B, K, CI, C ] D, R1, R2, L, ST
Back Scale
LL00, LL01, LL02, LL03, DF [ CF, CIF, CI, C ] D, LL3, LL2, LL1, LL0
Multilined Cursor: kW, HP
Archive - Larry Kehl collection


S548 Staedtler Mars 544-52 Log Log 		Staedtler Mars 544-52 Log Log (Jan 1969)
Made in Germany - date code 169
Front Scale
K, A [ B, CI, C ] D, L
Back Scale
25cm, S, ST, T, LL1, LL2, LL3, 10 inch
Multilined Cursor: kg/m, S, kW, HP


REF Staedtler-Noris 944-02 		Staedtler-Noris_944-02 - Open simplex
Made in Japan
Front Scale
L, K, A [ B, CI, C ] D, S, ST, T
Back Scale 25cm [S, LL1, Ll2, Ll3 ] 10in
Archive - Not in Collection


S131 Staedtler-Noris 944-03 		Staedtler-Noris_944-03 - Open simplex
Made in Japan
Front Scale
T1, T2, K, A [ B, CI, C ] D, S, ST, L
Back blank


ISRM Staedtler Mars 944-82 Log Log 		Staedtler Mars 944-82 Log Log
Made in Japan
Front Scale
T1 (Cot1), T2 (Cot2), DF [ CF, CIF, S' (Cos), C ] D, (P), S (Cos), ST (ST)
Back Scale
LL0, L, K, A [ B, BI, CI, C ] D, LL3, LL2, LL1
Multilined Cursor: kW, HP
Donated by David Hecht, Alexandria, VA


P178 Staedtler-Noris 945-03 		Staedtler-Noris_944-03 - Closed
Made in Japan
Front Scale
5in // K, A [ B, CI, C ] D, L
Back scale: [ S, ST, T ]

Standardgraph



REF - Standardgraph No. 910 Disco-Rietz		 Standardgraph No. 910 Disco-Rietz
Made in West Germany c1960 - 12.8cm diameter
Front Scale - L, CI, C ( D, Sin Cos, Tg Ctg, R)
Archive - Scan donated by John Krijnen, Netherlands

Tavernier - Gravet



REF Tavernier-Gravet 		Tavernier-Gravet - c1900
Made in France- Rue Mayet 19, Paris
Front Scale
25cm // A, DF [ CF, CI, C ] D \\ 25cm
Back Scale (Slide): [S, L, T ]
Cursor: Brass Chisel Point
Archive - Rod Lovett Collection


REF Tavernier-Gravet Chisel Cursor Mannheim 		Tavernier-Gravet Chisel Cursor Mannheim- c1900
Made in France - Rue Mayet 19, Paris
Front Scale
25cm // A [ B, C ] D
Back Scale (Slide): [S, L, T ]
Back: Equivalents (French)
Archive - Tom Dilatush Collection


REF Tavernier-Gravet Beghin 		Tavernier-Gravet Beghin - c1920
Made in France - Rue Mayet 19, Paris
Front Scale
25cm // A, DF [ CF, CI, C ] D, K, L
Back Scale (Slide): [S, T, B ]
Cursor: 3 hairlines
Archive - Giovanni Breda Collection


REF Tavernier-Gravet Mannheim 		Tavernier-Gravet Mannheim - dc8-28 (Aug 1928)
Made in France - Rue Mayet 19, Paris
Front Scale
25cm // A [ B, C ] D
Back Scale (Slide): [S, L, T (inverted) ]
Back: Equivalents (French)
Archive - Tom Dilatush Collection


REF Tavernier-Gravet Plastic 		Tavernier-Gravet Plastic - c1950
Made in Paris, France
Front Scale (extended)
25cm // A [ B, CI, C ] D
Back Scale (Slide): [S, S&T, T ]
Archive - Tom Dilatush Collection


REF Tavernier-Gravet Plastic 		Tavernier-Gravet Plastic - c1950
Made in Paris, France
Front Scale (extended)
25cm // A [ B, CI, C ] D
Back Scale (Slide): [S, S&T, T ]
Archive - Rod Lovett Collection


REF Tavernier-Gravet Beghin 		Tavernier-Gravet Beghin - dc 7-23(july 1923)
Made in France - Rue Mayet 19, Paris
Front Scale
35cm // A, DF [ CF, CI, C ] D, K, L
Back Scale (Slide): [S, T, B ]
Cursor: 3 hairlines
Archive - Tom Dilatush Collection

Tecnostyl



ISRM Tecnostyl 40/R Rietz (early) 		Tecnostyl 40/R Rietz (early)
Made in Italy
Front Scale
27cm // K, A [ B, CI, C ] D, L
Back Scale (Slide): [S, S&T, T ]
Cursor: 3 hairlines
Donated by David Hecht, Alexandra, VA


REF Tecnostyl 40/R Rietz (clear plastic) 		Tecnostyl 40/R Rietz (clear plastic)
Made in Italy
Front Scale
27cm // K, A [ B, CI, C ] D, L
Back Scale (Slide): [S, ST, T ]
Cursor: 3 hairlines
Archive - Herman van Herwijnen's SR Catalogue


REF Tecnostyl 41/C 		Tecnostyl 41/C
Made in Italy
Front Scale
14cm // A [ B, %, h, st, C ] D
Back Scale (Slide): [S, ST, T ]
Cursor: 3 hairlines
Archive - Herman van Herwijnen's SR Catalogue


REF Tecnostyl 41/C4 - Log Electrical tech 		Tecnostyl 41/C4 - Log Electrical tech
Made in Italy
Front Scale
14cm // A [ B, %, h, st,%, st, h, st, C ] D
Back Scale (Slide): [ B, %, h, st,%, st, h, st, C ]
Back: Wire gage table
Cursor: 3 hairlines
Archive - Herman van Herwijnen's SR Catalogue


REF Tecnostyl 41/D 		Tecnostyl 41/D
Made in Italy
Front Scale
14cm // P, K, A [ B, CI, C ] D, tg, sen
Back Scale (Slide): [LL1, LL2, LL3 ] 5.5 in
Cursor: 3 hairlines
Archive - Herman van Herwijnen's SR Catalogue


REF Tecnostyl 41/E Electro 		Tecnostyl 41/E Electro
Made in Italy
Front Scale
14cm // cosa, A(KW) [ B (PS), CI, C ] D, cosa
Back Scale (Slide): [S, lg, T ]
Cursor: 3 hairlines
Archive - Herman van Herwijnen's Slide Rule Catalogue


REF Tecnostyl 41/R 		Tecnostyl 41/R
Made in Italy
Front Scale
14cm // K, A [ B, CI, C ] D, L
Back Scale (Slide): [ S, S&T, T ]
Cursor: 3 hairlines
Archive - Herman van Herwijnen's SR Catalogue


REF Tecnostyl ST41 		Tecnostyl ST41
Made in Italy
Front Scale
14cm // K, A [ B, CI, C ] D, L
Back Scale (Slide): [ S, S&T, T ]
Archive - Herman van Herwijnen's SR Catalogue


REF Tecnostyl Calcolator Gegolo da Tavolo 		Tecnostyl Calcolator Gegolo da Tavolo
Made in Italy - 160mm diameter
Front Scale: A ( B )
Archive - Herman van Herwijnen's SR Catalogue


REF Tecnostyl Calcolator 		Tecnostyl Calcolator
Made in Italy - 160mm diameter
Front Scale: A ( B )
Archive - Herman van Herwijnen's SR Catalogue


REF Tecnostyl Regolo Per Trigonometria 		Tecnostyl Regolo Per Trigonometria
Made in Italy
Front Scale
Slide Chart for claculating right triangles
Back Scale: 12cm
Archive - Herman van Herwijnen's SR Catalogue

UNIS France

See more UNIS manufactured Slide Rules for Guedon in Misc USA.


REF UNIS France Electro 		UNIS France Electro
Made in France
Front Scale
13cm // KW, A [ B, C ] D,
Well: DYN MOT
Archive - Oliver Cassou Collection, France


REF UNIS France Marc No 5 Electricien 		UNIS France No 5 Electricien
Made in France
Front Scale
13cm // KW, A [ B, C ] D,
Well: DYN MOT
Archive - Herman van Herwijnen's SR Catalogue


REF UNIS France Marc No 6 		UNIS France Marc No 6
Made in France
Front Scale
13cm // K, A [ B, CI, C ] D, L
Slide: [ S,S&T, T]
Archive - Herman van Herwijnen's SR Catalogue


REF UNIS France Marc 		UNIS France Marc
Made in France
Front Scale
13cm // A [ B, C ] D
Archive - Herman van Herwijnen's SR Catalogue


REF UNIS France Régle Marc 		UNIS France Régle Marc
Made in France
Front Scale
13cm // K, A [ B, CI, C ] D, L
Slide: [ S,S&T, T]
Archive - Herman van Herwijnen's SR Catalogue

UTO



ISRM UTO No. 1 Studium 		UTO No. 1 Studium
Made in Denmark
Front Scale
A, DF [ CF, CIF, CI, C ] D, K
Back: Blank
Donated by David Hecht, Alexandria, VA


ISRM UTO 503 Studium 		UTO 503 Studium
Made in Denmark
Front Scale
27cm // L, K, A [ B, CI, C ] D, ST, T, S
Back: Blank
Font color=maroon>Donated by David Hecht, Alexandria, VA


ISRM UTO 561 Studium 		UTO 561 Studium
Made in Denmark
Front Scale
27cm // L, A, DF [ CF, CI, C ] D, ST ST, T Cot, S Cos
Back: Blank
Cursor: 3 Hairlines
Font color=maroon>Donated by David Hecht, Alexandria, VA


P133 UTO 601 - Barber-Colman 		UTO 601 - Barber-Colman
Made in Denmark
Front Scale
5inch // K, A [ B, CI, C ] D, L
Back Slider
[ S, S&T, T ]
Back Adv: Barber-Colman, Rockford,, Illinois


P059 UTO 601 - Hoffman - Cyanamid 		UTO 601 - Hoffman - Cyanamid
Made in Denmark, Distributed by Hoffman, USA
Front Scale
5inch // K, A [ B, CI, C ] D, L
Back Slider
[ S, S&T, T ]
Back Adv: Cyanamid [Phospahtes]


P018 UTO 601 - Hoffman - Lennox 		UTO 601 - Hoffman - Lennox
Made in Denmark, Distributed by Hoffman, USA
Front Scale
5inch // K, A [ B, CI, C ] D, L
Back Slider
[ S, S&T, T ]
Back Adv: Lennox Industries Inc.


P132 UTO 601 - Hoffman - Morris 		UTO 601 - Hoffman - Morris
Made in Denmark, Distributed by Hoffman, USA
Front Scale
5inch // K, A [ B, CI, C ] D, L
Back Slider
[ S, S&T, T ]
Back Adv: Morris Pumps, Baldwinsville, NY
Original Owner: WKM


S541 UTO 930U Poly-e 		UTO 930U Poly-e
Made in Denmark
Front Scale
L, K, A [ B, T Cot, ST, S Cos ] D, DI, P
Back Scale
LL01, LL02, LL03, DF [ CF, CIF, CI, C ] D LL3, Ll2, LL1
Original Owner: Robert Millar/Canada


REF UTO 930 Studium - Charvoz 		UTO 930 Studium
Made in Denmark
Front Scale
LL01, LL02, LL03, A [ B, L, K, C ] D, LL3, LL2, LL1
Back Scale
ST, T, T2 DF [ CF, CIF, CI, C ] D, DI, P, S
Archive - Rod Lovett collection


ISRM UTO 930 Studium 		UTO 930 Studium
Made in Denmark
Front Scale
LL01, LL02, LL03, A [ B, L, K, C ] D, LL3, LL2, LL1
Back Scale
ST, T, T2 DF [ CF, CIF, CI, C ] D, DI, P, S
Cursor: 3 Hairlines
Note: Very poor red ink, be careful in cleaning this model
Donated by David Hecht, Alexandria, VA


REF UTO 932 - Charvoz 		UTO 932 - Charvoz
Made in Denmark for Charvoz
Front Scale
LL00, K, A [ B, T Cot, ST, S Cos, C ] D, DI, LL0
Back Scale
LL01, LL02, LL03, DF [ CF, CIF, L, CI, C ] D LL3, Ll2, LL1
Archive - Rod Lovett collection


ISRM UTO F2145 		UTO F2145
Made in Denmark
Front Scale
11cm 4in // K, A [ B, CI, C ] D, L
Back Scale
[ S, S&T, T ]
Cursor: 3 Hairlines
Original Owner: C.W. Wright, Paris, Kentucky, USA
Note: Very poor red ink, be careful in cleaning this model
Donated by David Hecht, Alexandria, VA

VEB Electro-Apparate-Werke (EAW)



ISRM VEB Electro-Apparate-Werke (EAW) Pocket 		Veb VEB Electro-Apparate-Werke (EAW) Pocket- c1946
Made by Berlin-Treptow, DDR Germany - wood stock with plastic laminate
Front Scale
13cm // K, A[ B, CI, C ] D, L
Back Scale: [ sin, sin/tg, tg ]
Donated by David Hecht, Alexandria, VA
Note: VEB Electro-Apparate-Werke, later renamed Berlin-Treptow, was a public owned company founded in 1928 by Friedrich Ebert and made radios, relays and control equipment. Berlin-Treptow was one of the largest manufacturers of electric appliances in the GDR and had 8,000 employees. After Stalin's death the factory was renamed EAR JW Stalin. The company was privatized in 1993.




P107 Veb Mantissa Multi Pocket 		Veb Mantissa Multi Pocket - Closed simplex
Made in DDR/Germany
Front Scale
13cm // ST, A, DF [ CF, CIF, CI, C ] D, P, S, T
Back Slider: [ LL1, LL2, LL3, L ]
Cursor: 3 hairlines


S059 Veb Mantissa Mono Rietz 1731-541 		Veb Mantissa Mono Rietz 1731-541 - Simplex
Made in DDR/Germany
Front Scale
L, K, A [ B, CI, C ] D, S, T, ST
Back Slider: Blank
Cursor: 3 hairlines


S200 Veb Mantissa 1731-511 Rietz 		Veb Mantissa 1731-511 Rietz - Duplex
Made in DDR/Germany
Front Scale
K, A [ B, CI, C ] D, L
Back Scale: [ S, ST, T ]
Cursor: 3 hairlines


S163 Veb Mantissa Darmstadt II 1731 523/4 		Veb Mantissa Darmstadt II 1731-523/4
Made in DDR/Germany
Front Scale
K, A [ B, CI, C ] D, L
Back Scale
P, ST [ LL1, LL2, LL3] D, T, S


REF Veb Mantissa Record 1731-421 		Veb Mantissa Record 1731-421
Made in DDR/Germany
Front Scale
L, K, A [ B, CI, C ] D, LL1, LL2, LL3
Back Scale
P, S, ST, DF [ CF, CIF, CI, C ] D, T1, T2, DI
Archive - Not in Collection


ISRM Veb Mantissa Mono Rietz 1731 541 		Veb Mantissa Mono Rietz 1731 541
Made in DDR/Germany
Front Scale
L, K, A [ B, CI, C ] D, S, T, ST
Back: Blank


REF Veb Mantissa Trim LL 1731-433 		REF Veb Mantissa Trim LL 1731-433
Made in DDR/Germany
Front Scale
P, S, K, A [ B, L, CI, C ] D, T1, T2, DI
Back Scale
LL01, LL02, LL03, DF [ CF, CIF, CI, C ] D, LL3, LL2, LL1
Archive - Rod Lovett Collection

Vittorio Martini, Antica Fabbrica



REF Antica Fabbrica Vittorio Martini Elettro (Electro) 401 		Antica Fabbrica Vittorio Martini Elettro (Electro) 401
Made in Italy
Front Scale
14cm // Volt, A [ B, CI, C ] D, U \\ 5 Inch
Back Scale (Slide): [ S, ST, T ]
Cursor: Multiple hairlines C, -C
Archive - Giovanni Breda Collection


REF Antica Fabbrica Vittorio Martini Elettro Cosfi (Electro) 402 		Antica Fabbrica Vittorio Martini Elettro Cosfi (Electro) 416
Made in Italy
Front Scale
14cm // Volt, A [ B, CI, C ] D, Cosfi \\ 5 Inch
Back Scale (Slide): [ S, ST, T ]
Cursor: Multiple hairlines C, PS/kW
Archive - Giovanni Breda Collection


REF Antica Fabbrica Vittorio Martini Darmstadt 404 		Antica Fabbrica Vittorio Martini Darmstadt 404
Made in Italy
Front Scale
14cm // P, K, A [ B, CI, C ] D, S, T, L
Back Scale (Slide): [ LL1, LL2, LL3 ]
Cursor: Multiple hairlines C, PS/kW
Archive - Giovanni Breda Collection


REF Antica Fabbrica Vittorio Martini Rietz 3991 		Antica Fabbrica Vittorio Martini Rietz 3991
Made in Italy
Front Scale
14cm // K, A [ B, CI, C ] D, L \\ 5 inch
Back Scale (Slide): [S, ST, T ]
Cursor: Multiple hairlines C, -C
Archive - Giovanni Breda Collection


REF Antica Fabbrica Vittorio Martini Rietz 25 		Antica Fabbrica Vittorio Martini Rietz 25
Made in Italy
Front Scale
26cm // K, A [ B, CI, C ] D, L ||10 inch
Back Scale (Slide): [S, ST, T ]
Cursor: Multiple hairlines C, -C
Archive - Giovanni Breda Collection


REF Antica Fabbrica Vittorio Martini Rietz 25 		Antica Fabbrica Vittorio Martini Rietz 25
Made in Italy
Front Scale
26cm // K, A [ B, CI, C ] D, L ||10 inch
Back Scale (Slide): [ S, ST, T ]
Cursor: Multiple hairlines C, -C
Archive - Giovanni Breda Collection


REF Antica Fabbrica Vittorio Martini Darmstadt 417 		Antica Fabbrica Vittorio Martini Darmstadt 417
Made in Italy
Front Scale
26cm // K, A [ B, CI, C ] D, P, S, T || L
Back Scale (Slide): [ LL1, LL2, LL3 ]
Cursor: Multiple hairlines C, PS/kW
Archive - Giovanni Breda Collection


REF Antica Fabbrica Vittorio Martini Elettro Cosfi (Electro) 416 		Antica Fabbrica Vittorio Martini Elettro Cosfi (Electro) 416
Made in Italy
Front Scale
26cm // Volt, A [ B, CI, C ] D, Cosfi, K, LL(A)|| L
Back Scale (Slide): [ S, ST, T ]
Cursor: Multiple hairlines C, PS/kW
Archive - Giovanni Breda Collection

Gebr. Wichmann (Wichmann Brothers)



REF Gebr, Wichmann 431 		Gebr. Wichmann 431 c1900
Made in Berlin, Germany by Wichmann Brothers - Paper composite with brass chisel cursor
Front Scale
A [ B, C ] D
Back: Blank
Archive - Ed Chamberlain Collection


REF Gebr. Wichmann 466 		Gebr. Wichmann 466 c1900
Made in Berlin, Germany by Wichmann Brothers - Paper composite with brass chisel cursor
Front Scale
A [ B, C ] D
Back: Blank
Archive - Ed Chamberlain Collection


REF Gebr. Wichmann 1327-1/2		 Gebr. Wichmann 1327-1/2
Made in Germany by Gebr. Wichmann m.b.h. (Wichmann Brothers)
Front Scale
A [ B, C ] D
Archive - Herman van Herwijnen's SR Catalogue


REF Wichmann 4428		 Gebr. Wichmann 4428
Made in Germany by Gebr. Wichmann m.b.h. (Wichmann Brothers)
Front Scale
A [ B, C ] D
Back scale: 27.2cm [S, L, T ] 10.75in
Archive - Scan provided by Mark D. Sutton

Wolters-Noordhoff



REF Wolters-Noordhoff Rietz 87 		Wolters-Noordhoff Rietz 87
Made in Japan (Fuji) for Dutch Company
Front Scale
K, A [ B, CI, C ] D, L
Back Slide
0-15cm, 15-0cm [ S, T, T1 ]
Archive - Herman van Herwijnen's SR Catalogue


S062 Wolters-Noordhoff FJ102 		Wolters-Noordhoff FJ102 - Simplex
Made in Japan (Fuji) for Dutch Company
Front Scale
L, DF [ CF, CIF, CI, C ] D, A, K
Back Slide
25cm [ S, ST, T1, T2 ]
Cursor: 3 hairlines


REF Wolters-Noordhoff 112 		Wolters-Noordhoff 112
Made in Japan by Fuji
Front Scale
L, DF [ CF, CIF, CI C ] D, A, K
Cursor: 3 hairlines: PS, KW, C
Back Scale
25cm [ S Cos, ST
, T1 Cot1, T2 Cot2 ]
Archive - Rod Lovette Collection


REF Wolters-Noordhoff JE650 		Wolters-Noordhoff JE650 - Duplex
Made in Germany for Dutch Company
Front Scale
A, DF [ CF, CIF, CI, C ] D, K
Back Scale
L, T1 Cot1, T2 Cot2 [ S', CI, C ] D, S Cos, ST
Cursor: 3 hairlines
Archive - Herman van Herwijnen's SR Catalogue


S063 Wolters-Noordhoff 1200 		Wolters-Noordhoff 1200 - Duplex
Made in DDR/Germany
Front Scale
T1 Cot1, T2 Cot2, A [ B, BI, CI C ] D, P, S Cos, ST
Back Scale
LL1, LL2, LL3, DF [ CF, CIF, CI C ] D, L, K
Cursor: 3 hairlines: PS, KW, C

Zulaica y Cia



REF Zulaica Stilus 		Zulaica Stilus (c1930)
Made in Spain by Zulaica y Cia S.R.C., Zarauz, Guipuzcoa, Basque region
Front Scale
A [ B, CI, C ] D
Back
Equivalents and constants
Archive - Herman van Herwijnen's SR Catalogue
Copyright © 2003-2006 International Slide Rule Museum
