A.W. Faber 44/87 Rietz (20inch/50cm)

L10

L10 A.W. Faber 44/87 Rietz (20inch/50cm)
Made in Germany - date code 53
Front Scale (Extended): 20inch // K, A [ B, CI, C ] D, L || 50cm
Back Slider: [ Sin Cos, Sin/tg, Tan Cot ] Back: Equivalents


Faber-Castell 4/22 Business Slide Rule (20 inch)

ISRM 13.10.09.04

Model number in well

Special adjustment tool supplied by manufacturer.
Faber-Castell 4/22 Business Slide Rule (20inch)
Made in Germany - date code 53
Front Scale (Extended): 20inch // International conversion marks for weights and measures, DIF(P)(Int.) [ DIF(D), Val.(CI)C, C(P.P.)(D), ] D(S.P.)(Int.), L || sh/d, £
Back Scale: [ Exponential graduation for calculation of compound interest, C ]
Back: Instructions and Equivalents
Multiple hairlines, wrap-over cursor
Gift of Phillip Rodley, Upper Hutt, New Zealand

Note the small sheet-metal tool/screwdriver attached to the green sleeve in the image to the left. This was supplied with the slide rule so the user could loosen the cursor screws to calibrate the hairlines on the top and side and adjust the tension on the slide. These were easily lost because of their small size, and the first one acquired by ISRM.



Faber Castell 4/54 Darmstadt (50cm)

REF
Faber Castell 4/54 Darmstadt (50cm)
Made in Germany.
Front Scale (Extended): 50cm, L // K, A [ B, CI, C ] D, P || sin/cos, tg/ctg
Back Slider: [ LL1, LL2, LL3 ] Back: Equivalents
Archive - Courtesy of the Atsushi Tomozawa Collection, Japan



A.W.Faber Slide Rule C1892

REF
A.W.Faber Slide Rule C1892
Made in Germany
Front Scale
25cm // A [ B, C] D \\ 10in
Back Scale: Meter to inch conversion
Note: Cursor spring rides on angled bevel
Archive - Warren Burdine Collection


A.W. Faber Calculating Rule

REF S561
A.W. Faber Calculating Rule - 1897-1906
Made in Germany (Bavaria) - English Text
Front Scale
10in // A [ B, C] D || 26cm
Well: 27-52cm
Back Scale: [ S, L, T ]
Back: Conversions (English)
Original Owner: Millar
Note: Cursor spring rides on angled bevel




A.W. Faber Calculating Rule

REF S406
A.W. Faber Calculating Rule 1897-1906
Made in Germany (Bavaria) - English Text
Front Scale
10in // A [ B, C] D || 26cm
Well: 27-52cm
Back Scale: [ S, L, T ]
Back: Conversions (English)
Note: Cursor spring rides on angled bevel


A.W. Faber Calculating Rule

REF S342
A.W. Faber Calculating Rule 1897-1906
Made in Germany (Bavaria) - English Text
Front Scale
10in // A [ B, C] D || 26cm
Well: 27-52cm
Back Scale: [ S, L, T ]
Back: Conversions (English)
Note: Cursor spring rides on standardized square bevel




A.W.Faber 349 System Hohenner

REF P194
A.W. Faber Calculating Rule
Made in Germany
Front Scale
14cm // A [ B, C] D || 15cm
Back Scale: [ S, L, T ]
Back: Conversions (German)


Faber-Castell 357

REF
Faber-Castell 357 with Decimal Tracker
Made in Germany (Bavaria) - D.R. Patent 206408
Front Scale
27cm // A [ B, C] D || 29cm
Well: 35-55cm
Back Scale: [ S, L, T ]
Back: Conversions (German)
Archive - Herman van Herwijnen's SR Catalog


A.W. Faber (357), Decimal Tracker

ISRM 15.09.27.03
A.W. Faber (357) with Decimal Tracker (c1896-1899)
Made in Germany (Bavaria) - D.R. Patent 98350, 116832
Note: Railroad Track style divisions. pre-rivet celluloid (slide laminate has shrunk)
Front Scale
27cm // A [ B, C] D || 29cm
Well: 35-55cm
Back Scale: [ S, L, T ]
Back: Conversions (unreadable)
Provided by the Tom Wyman Collection


Faber-Castell 360

REF S117
Faber-Castell 360
Made in Germany (Bavaria) - D.R. Patent 206408
Front Scale
27cm // A [ B, C] D || 28cm
Well: 35-55cm
Back Scale: [ S, L, T ]
Back: Conversions (German)
Original Owner/Location: Taken off German Soldier during WWII/DDR Germany


A.W. Faber "Castell" 360 (1903) (English)

ISRM 14.10.14.02
A.W. Faber "Castell" 360 (English) dc3-3
Made in Germany (Bavaria) - D.R. Patent 206408
Front Scale
10in // A [ B, C] D || 28cm
Back Scale: [ S, L, T ]
Back: Conversions (English)
Original Owner/Location: England


A.W. Faber "Castell" 360 (English)

REF S329
A.W. Faber "Castell" 360
Made in Germany (Bavaria) - D.R. Patent 206408
Front Scale - Extended
10in // A [ B, C] D || 29.5cm
Back Scale: [ S, L, T ]
Back: Conversions (English)
Original Owner/Location: England. Initials on stock:HGM


Faber-Castell 361 (English)

REF S526
Faber-Castell 361
Made in Germany (Bavaria)  - D.R.P. (Patent Pending)
Front Scale - Extended
10in // A [ B, C] D || 29.5cm
Back Scale: Blank
Back: Conversions (English)
Original Owner/Location: England


A.W. Faber 367 Mannheim (1909-1912)

ISRM 16.07.01.01
A.W. Faber 367 Mannheim
Made in Bavaria. Note 'Railroad track' style divisions
Front Scale(extended)
10 inch // A [ B , C ] D \\ 28 cm
Well: 28-56cm
Back Slide: [ S, L, T ]
Cursor: Decimal Keeper (missing lens)
Back: Conversions (English) faded
Original Owner Unknown
Gift of Phillip Rodley of Upper Hutt, New Zealand


A.W. Faber 368 Elektro (1909-1912)

ISRM 13.11.05.04
A.W. Faber 368 Elektro - Version 2
Made in Bavaria. Note 'Railroad track' style divisions
Front Scale(extended)
27cm // A (KW) [ B (mm2)(HP), CI, C (Watt) ] D, \\ LL03, LL2
Well: Dynamo, Motor TL=%, Volt
Back Slide: Metal edge cursor for well [ S, L, T ]
Cursor: Metal tab for edge scales.
Back: Conversions (English)
Original Owner (marked on case): Doug Hamilton, New Zealand.
Gift of Phillip Rodley of Upper Hutt, New Zealand


A.W. Faber "Castell" 369

REF
A.W. Faber "Castell" 369
Made in Germany (Bavaria) - D.R.P.206428
Front Scale - Extended
14cm// A [ B, C] D || 5in
Back Scale: [ S, L, T ]
Back: Conversions (German)
Archive - Hermans Slide Rule Catalogue collection


A.W. Faber 374 System Pickworth

REF
A.W. Faber 374 System Pickworth
Made in Germany (Bavaria) - Designed by C.N. Pickworth, Wh. Sc., England
Front Scale
27cm // A [ B, C] D || 29cm
Back Scale: [ S, L, T ]
Back Window Scale: K [ L ]
Archive - Herman van Herwijnen's SR Catalog


A.W. Faber "Castell" 375 System Rietz (c1929)

ISRM 14.05.01.02

Instructions for Model 361 which came with this model 375 slide rule. (4.90MB PDF). It is in very poor condition and is missing 1/3 of one page.

A.W. Faber "Castell" 375 System Rietz
Made in Bavaria - D.R. Patent 206408
Note: Railroad Track style divisions, riveted laminations
Front Scale
10in // K, A [ B, C1, C ] D, L || 29cm
Back Slide: [ cos, sin/tg, ctg ]
Back: Conversions (English)
Original Owner: .J.H.N. Haigh (marked on slide rule, case and manual) presumably of New Zealand.
Gift of Phillip Rodley, New Zealand



A.W. Faber "Castell" 378 Electro (c1929)

ISRM 14.01.03.01
A.W. Faber "Castell" 378 Electro
Made in Bavaria - D.R. Patent 206408
Note: Railroad Track style divisions, riveted laminations
Front Scale
27cm // LL2, A (Kw) [ B (mm2)(H.P.), C (Watt) ] D, LL03 || Log (Note:25.4cm long)
Well: Motor TL=%, Volt
Back Slide: [ S, L, T ]
Back: Conversions (English)
Gift of Phillip Rodley, Upperhutt, New Zealand
Faber-Castell 378 Instructions (c1929) Slide Rule Instructions (Spanish ) 2.56MB. Scan By José G Fernández, Spain. Courtesy of reglasdecalculo.com



A Specimen with Faber cursor
A.W. Faber "Castell" 379 Electro (c1920)
ISRM 13.10.07.02
A.W. Faber "Castell" 379 Electro (Date Code 0)
Made in Germany - D.R. Patent 206408
Note: Railroad Track style divisions, riveted laminations
Front Scale: 14cm // LL2, A (Kw) [ B (mm2)(H.P.), C (Watt) ] D, LL03 || Log (Note:12.7cm long scale)
Well: Motor TL=%, Volt
Back Slide: [ S, L, T ]
Back: Conversions
Original Owner: Dr. Lee J. W. Levent, Hell Gate Power Station, (Marked on Back of stock) in South Bronx, New York.
Archive Scan with cursor (green background) Jorge Fabregas collection, Spain - reglasdecalculo.com
Historical Note: The Hell Gate Power Station, where this slide rule was used, was built in Bronx, New York in 1921, by Thomas E. Murray (1860-1929) of the United Electric Light & Power Company and later operated by Consolodated Edison. It was closed in 1973. It assumed the owner of the above slide rule, Dr. Lee J. W. Levent, was one of the many engineers on the project. The title Dr., in this case, being a Ph.D in electrical engineering. Thomas E. Murray was responsible for the design and construction of nine power stations in New York City, most of which continued to operate well into the second half of the 20th century.Murray built three stations in the city during the 1920s, each among the largest ever constructed anywhere. The first, Hell Gate, was undertaken by United to supplement Sherman Creek and supply the northern suburbs and Queens. Named for the mariner's term for the treacherous currents where the East River meets Long Island Sound, Hell Gate opened in November 1921. Planned for a capacity of 280 MW, so rapid was the advance in component design that it was actually rated at 605 MW to make it the world's most powerful steam electric station upon installation of the last unit in 1928. Hell Gate introduced Murray's most significant nonelectrical innovation for power stations: the water-cooled steel furnace wall to replace the fire brick refractory furnace wall used previously. The steel wall was comparatively thin, which afforded a substantial increase in furnace capacity and a major reduction in maintenance expense. This Murray innovation became the industry standard after the successful test at Hell Gate.


P070 Faber-Castell 389 10cm
Faber-Castell 389 10cm
Made in Germany
Front Scale
10cm // A [ B, C ] D
Back slider: [ S, l, T
Back: Blank
Original Owner/Location: Hartmut A. Niemann/Germany


Faber-Castell 398 Electro (all glass cursor)

ISRM 11.12.17.01
Faber-Castell 398 Electro
Made in Germany
Front Scale(extended)
27cm // LL2, A (KW) [ B (PS), CI, C (Watt) ] D, LL03 || LL
Well: Dynamo, Motor TL=%, Volt
Back Slide: [ S, L, T ]
Cursor: Multiple Hairlines: W, PS/q, d
Back: Blank
Original Owner (marked on back of stock): Robert Kaoga


S441 Faber-Castell 398 Electro (Metal framed cursor)
Faber-Castell 398 Electro
Made in Germany for Australian Market
Front Scale (extended)
10in // LL2, A (Kw) [ B (H.P.), deg rise, CI, C (Watt) ] D, LL03 || LL
Well: Dynamo, Motor TL=%, Volt
Back Slide: [ S, L, T ]
Back: Conversions (English)
Original Owner/Location: W.F. Backhouse/Australia




Faber-Castell 1/22 Business Slide Rule (1959)

ISRM 14.07.22.06
Faber-Castell 1/22 Business Slide Rule dc 11-59
Made in Germany
Front Scale (extended)
10in // Conversion, DF(KZ) [ CF, CI (p%), C(T) ] D(Z), L || sh/d, Pounds Sterling
Back Slide: [ LL1, LL2, %, C ]
Channel: CM scale Cursor: 3 hairlines
Back: Instructions, Conversions, Parities.
Gift of Phillip Rodley, Upperhutt, New Zealand


S056 Faber-Castell 111/22 Disponent
Faber-Castell 111/22 Disponent
Made in Germany
Front Scale (extended)
27cm // Conversion, DF(KZ) [ CF, CI (p%), C(T) ] D(Z), L, sh/d, Pounds Sterling
Back Slide: [ LL1, LL2, %, C ]
Channel: CM scale Cursor: 3 hairlines
Back: Instructions
Original Owner/Location: UNK/Germany


Faber-Castell 1/28 Super-Business

ISRM 14.05.01.03
Faber-Castell 1/28 Super-Business - dc11-07
Made in Germany
Front Scale (extended)
27cm, L // K, DF(P/Int) [ CF(Days), CI(R%), C(Days) ] D(Int), A || sin/cos, tg/ctg
Back Slide: [ LL1, LL2, C ]
Cursor: 4 hairlines
Back: Monetary Conversion tables, Units conversions.
Gift of Phillip Rodley, Upperhutt, New Zealand

Instructions (791KB PDF) and Plastic case with clamshell lid.


Faber-Castell 111-48 System Dr. Winkel

REF S307
Faber-Castell 111-48 System Dr. Winkel
Made in Germany
Front Scale (machining speeds and feeds)
Back: Reference Tables
Archive - Jim Cerny Collection See another at Hubert van Dongen (Netherland) Collection an ISRM associate.



Faber-Castell 1/54 Darmstadt (Import) V1

REF S037
Faber-Castell 1/54 Darmstadt (Import) V1
Made in Germany
Front Scale (extended)
27cm, lg // K, A [ B, CI, C ] D, P || sin/cos, tg/ctg
Back Slide: [ CF, CIF, C ]
Note: Compare back of slide with the Aug 1970 1/54 below. It has the [ LL1, LL2, LL3 ] scales.
Well (Channel): Centemeter scale 33.2 to 56.8cm
Note: The stock is 30cm long. When you extend the slide, the reading of the left edge of the slide on the inch scale in the well gives the overall length of the stock and slide.
Cursor: 3 hairlines
Back: Instruction (German) label dcK8sv, "Import" stamp on stock.
Original Owner/Location: M. Bergfors/Germany



Faber-Castell 1/54 Darmstadt (Aug 1970) V2

ISRM 13.12.03.03
Faber-Castell 1/54 Darmstadt dc870-54 V2
Made in Germany
Front Scale (extended)
27cm, lg // K, A [ B, CI, C ] D, P || sin/cos, tg/ctg
Back Slide: [ LL1, LL2, LL3 ]
Note: Compare back of slide with the Import 1/54 above. It has the [ CF, CIF, C ] scales.
Well (Channel): Centemeter scale 33.2 to 56.8cm
Note: The stock is 30cm long. When you extend the slide, the reading of the left edge of the slide on the inch scale in the well gives the overall length of the stock and slide.
Cursor: 3 hairlines
Back: Instruction (German) label dcK8d



Faber-Castell 1/54A Darmstadt with Addiator

ISRM 13.08.12.07
Faber-Castell 1/54A Darmstadt with Addiator
Made in Germany
Front Scale (extended)
27cm, lg // K, A [ B, C1, C ] D, P || sin/cos, tg/ctg
Back Slide: [ CF, CIF, C ]
Well (Channel): Inch scale 12 to 22-5/8 inches
Note: The stock is 12" long. When you extend the slide, the reading of the left edge of the slide on the inch scale in the well gives the overall length of the stock and slide.
Cursor (wrap around edges): 7 hairlines/gauge marks A-B Scales: s, kW, HP. C-D Scales: kW, s, HP. Lg, sin, tg scales
Back: Mechanical Addiator for addition and subtraction. Instructions.
Note: The Stylus for the Addiator is mounted in a bored hole at the left end of the stock.
Original Owner/Location: J.W. Hand of Christchurch, New Zealand.
Gift of Phillip Rodley, Upper Hutt, New Zealand.



Faber-Castell 111/54 Darmstadt (early)

REF S161
Faber-Castell 111/54 Darmstadt
Made in Germany
Front Scale (extended)
27cm // K, A [ B, CI, C ] D, P, S, T || lgX
Back Slider: [LL1, LL2, LL3]
Multiple hairlines PS, KW, q, d
Original Owner/Location: Unk/Hungary


Faber-Castell 111/54 Darmstadt

REF S162
Faber-Castell 111/54 Darmstadt
Made in Germany
Front Scale (extended)
27cm // K, A [ B, BI, CI, C ] D, S, ST, T, P || lgX
Back Slider: [ LL1, LL2, LL3 ]
Multiple hairlines PS, KW, q, d
Original Owner/Location: Unk/Hungary


Faber-Castell 1/60 Mannheim

REF S429
Faber-Castell 1/60 Mannheim
Made in Germany
Front Scale (extended)
27cm // A [ B, CI, C ] D || 1:25 mm
Back Scale: [sin cos, lg, tg ctg ]
Well: 33-60cm scale
Note: The stock is 30cm long. When you extend the slide, the reading of the left edge of the slide on the inch scale in the well gives the overall length of the stock and slide.
Back: Equivalents (German)
Original Owner/Location: Unk/England


Faber-Castell 1/60/360 Mannheim (Sep 1937)

ISRM 13.09.16.01
Faber-Castell 1/60/360 Mannheim dc37-10
Made in Germany
Front Scale (extended)
10inch // A [ B, CI, C ] D || 30cm
Back Scale: [sin cos, lg, tg ]
Well: 33-60cm scale
Note: The stock is 30cm long. When you extend the slide, the reading of the left edge of the slide on the inch scale in the well gives the overall length of the stock and slide.
Back: Equivalents (English)
Original Owner/Location: Unk/England


Faber-Castell 1/60 Mannheim (1940)

ISRM 14.07.02.32
Faber-Castell 1/60 Mannheim
Made in Germany - Date code June 1940.
Front Scale (extended)
27cm // A [ B, CI, C ] D || 1:25 mm
Back Scale: [sin cos, lg, tg ctg ]
Well: 33-60cm scale
Note: The stock is 30cm long. When you extend the slide, the reading of the left edge of the slide on the inch scale in the well gives the overall length of the stock and slide.
Back: Equivalents (German)
Original Owner/Location: Unk/England


Faber-Castell 111/66 Demegraph System Schirmer

ISRM 14.07.22.04
Faber-Castell 111/66 Demegraph System Schirmer Typesetters Rule
Made in Germany - One piece plastic cursor
Front Scale (extended)
10in // differentials (yards), DF(P/Int) [ CF(Days), CI(R%), C(Days) ] D(Int), Area, Yards 1, Yards 2, Yards 3
Back Slide: [ LL1, LL2, C ]
Cursor: 5 hairlines
Back: 0-42, Pica font sizes 1-128, 0-42
Gift Of Phillip Rodley, Upperhutt, New Zealand


Faber-Castell 1/87 Rietz

REF S169
Faber-Castell 1/87 Rietz
Made in Germany - metal framed cursor
Front Scale (extended)
27cm // K, A [ B, CI, C ] D, L
Back Slide: [ cos, sin/tg, ctg ]
Cursor: 3 hairlines
Back: Conversions (English)
Original Owner/Location: M. Bergfors/Germany


Faber-Castell 1/87 Rietz

REF S505
Faber-Castell 1/87 Rietz
Made in Germany - aluminum cursor guide pinned to lens
Front Scale (extended)
27cm // K, A [ B, C1, C ] D, L
Back Slide: [ cos, sin/tg, ctg ]
Cursor: 3 hairlines
Well: 33-60cm (used with tab on slide)
Back: Conversions (German)


A.W. Faber "Castell" 1/87 System Rietz 1943

ISRM 13.02.01.01
A.W. Faber "Castell" 1/87 System Rietz - dc 43-8 (Aug 1943)
Made in Germany - metal edged cursor
Front Scale (extended) scales labeled
27cm // K, A [ B, CI, C ] D, L || 1:25 0-7in
Back Slide: [ Sin Cos, Sin/Tg, Tg Ctg ]
Cursor: 5 hairlines: HP, KW, PS, d, s. Labels stamped in sheetmetal.
Back: Conversions (German)
Original Owner: Frank Woodin Barnett (1889 - 1958)
Donated by Raymond DuBois of Camas, Washington.

Frank Barnett
Raymond DuBois, the grandson of Frank Barnett, writes: "This slide rule belonged to my grandfather. He joined the faculty at Piedmont High School in Piedmont, California in 1922 and conducted classes in mechanical drawing, manual training and wood and print shop instruction. He retired in 1956 and died in 1958 of leukemia."


Faber-Castell 1/87 Rietz (1954)

ISRM 14.07.22.05
Faber-Castell 1/87 Rietz dc5-54
Made in Germany - all plastic cursor, Castell on slide
Front Scale (extended) scales labeled
10inch // K, A [ B, CI, C ] D, L || 30cm
Back Slide: [ S Cos, ST, T Ctg ]
Cursor: 5 hairlines: HP, KW, PS, d, s
Back: Conversions (English) Note: gummed label
Gift of Phillip Rodley, Upper Hutt, New Zealand


Faber-Castell 1/87 Rietz

REF S118
Faber-Castell 1/87 Rietz
Made in Germany - all plastic cursor, Castell on slide
Front Scale (extended) scales labeled
10inch // K, A [ B, CI, C ] D, L || 30cm
Back Slide: [ S Cos, ST, T Ctg ]
Cursor: 5 hairlines: HP, KW, PS, d, s
Back: Conversions (English) Note: Printed plastic film.
Original Owner/Location: Unk/Germany


Faber-Castell 1/87A Rietz with Addiator

ISRM 14.05.01.01
Faber-Castell 1/87A Rietz with Addiator
Made in Germany - all plastic cursor
Front Scale (extended) scales labeled
10inch // K, A [ B, CI, C ] D, L || 30cm
Back Slide: [ S Cos, ST, T Ctg ]
Cursor: 5 hairlines: HP, KW, PS, d, s
Back: Addiator with scribe tool, Conversions (English)
Gift of Philip Rodley, Upper Hutt, New Zealand
Instructions (11.3MB pdf)


Faber-Castell 1/94/394 (Joe Klawun No.25) Sys.Rietz (Dec 1938)

ISRM 13.09.16.03
Faber-Castell 1/94/394 (Joe Klawun No.25) Sys.Rietz dc38-12
Made in Germany for Feinmessinstitut Joe Klawun, Berlin - Charlottenburg 5
Note: "Railroad track" style division
Front Scale (extended) scales labeled
27cm // K, A [ B, CI, C ] D, L || 10inch
Back Slide: [ S Cos, ST, T Ctg ]
Cursor: Metal framed
Back: Conversions (German)
Original Owner: Spordeler (on back of stock)


Faber-Castell 1/98 Elektro

REF S172
Faber-Castell 1/98 Elektro
Made in Germany
Front Scale (extended)
27cm // LL2, A(kw) [ B, CI, C ] D, LL3 || L
Back Slide: [ sin cos, lg, tg ctg ]
Well: Dynamo, Efficiency, Volt
Note: the metal edge on the left end of the slide is used to transfer the readings from the scales in the well.
Cursor: Multiple hairlines: PS, KW
Back: Conversions (German)
Original Owner/Location: Hartmut A. Niemann/Germany
Images needed
Faber-Castell 111/98 Elektro
REF
Faber-Castell 111/98 Elektro
Made in Germany
Front Scale (extended)
10inch // LL2, A(kw) [ B, CI, C ] D, LL3, W, V, K
Back Slide: [ sin cos, lg, tg ctg ]
Cursor: Multiple hairlines: PS, KW
Back: Properties,Formulae/Conversions:Maths;Mech;Elect;Civil Eng;Physics.


Faber-Castell 1/98/398 Elektro (1937)

REF S290
Faber-Castell 1/98/398 Elektro dc37
Made in Birnbaum,Germany by A.W. Faber
Material: Celluloid laminated Pearwood
Front Scale (extended)
10in // LL2, A(kw) [ B(hp), Temp°, C1, C ] D, LL3 || K
Back Slide: [ sin/cos, lg, tg ]
Well: Efficiency, Volt
Cursor: 3 hairlines: W, Hp, d, metal wrapped and divided with hairline for bottom 'K' scale
Back: Conversions (English)
Original Owner/Location: N.T. Chen/Hong Kong, China

Note: First two characters mean "Germany" the last "Made In"


Faber-Castell 1/98/398 Elektro (1938)

ISRM 13.12.07.01
Faber-Castell 1/98/398 Elektro dc38-4
Made in Birnbaum,Germany by A.W. Faber
Material: Celluloid laminated Pearwood
Front Scale (extended)
10in // LL2, A(kw) [ B(hp), Temp°, C1, C ] D, LL3 || K
Back Slide: [ sin/cos, lg, tg ]
Well: Efficiency, Volt
Cursor: 3 hairlines: W, Hp, d, metal wrapped and divided with hairline for bottom 'K' scale
Back: Conversions (English)
Original Owner: W. Craick (marked on stock). This specimen was obtained in Adelaid, Australia.


Faber-Castell 2/82 Duplex

ISRM 11.10.26.01
Faber-Castell 2/82 Duplex (dc 1157)
Made in Germany - 24 scales
Front Scale
Cot1 T1, T2 Cot2, A [ B, BI, CI, C ] D, P, S Cos P
Back Scale
LL03, LL02, LL01, K [ K', L, ST, CF ] DF, LL1, LL2, LL3
Multiple hairlines: 360, d, A, KW, PS
Original Owner: Roman Marian Russek (1933-2011)
Donated by Shiela Russek, Toronto, Canada, wife or Roman Russek. Photo provided by daughter Irene Casey (nee Russek).
Roman Marian Russek (1933-2011)was known for his wide knowledge of power cables and, in later years, for his expertise the transfer of technology within international joint ventures. At the close of WWII Roman was a member of the Polish Army under British command. With Communism descending on his homeland his left to study in Britain where he earned engineering degrees from Heriot Watt University (Edinburgh) and London University. By 1949 he was a Scientific Officer in the Wood Lane Research Laboratories of British Insulated Callenders Cables in London. There he was assigned to teams studying the mechanical behavior of aluminum sheaths, electrical characteristics of oil impregnated paper as well as assisting in the development of flexible joints for submarine cables destined to be used in the HVDC link between North and South Island in New Zealand. As Design Engineer and then Department Manager Roman traveled widely within Canada and internationally representing CWC in many negotiations and discussions with customers and associated firms. He was fluent in five languages. Later as Vice-President Technical Services Roman spent another 14 years transferring technology from the domestic company to the many fledgling associate companies in Mexico, Colombia, Venezuela, Dominican Republic, Ireland, Spain, Brazil. South Africa, Nigeria, New Zealand, Australia and Iran. Roman and his wife Shiela spent much of their retirement years traveling around the world. Read this An article about Roman Russek by his friend XAVIER KATAQUAPIT


Faber-Castell 2/82 Duplex

ISRM 12.06.24.01
Faber-Castell 2/82 Duplex
Made in Germany - 24 scales
Front Scale
L, T1, T2, A [ B, BI, CI, C ] D, ST, S, P
Back Scale
LL03, LL02, LL01, K [ K', C, CIF, CF ] DF, LL1, LL2, LL3
Multiple hairlines: 360, d, A, KW, PS

Mr. Huang
Donated by the Huang Collection.
The collector, who prefers to remain anonymous, obtained a B.S. degree in Physics from Taiwan's National Tsing Hua University in 1971. His love for computation has encouraged him to build a collection of slide rules, HP and TI calculators, as well as abaci, many displayed at ISRM.


Faber-Castell 2/82N Duplex

REF
Faber-Castell 2/82N Duplex
Made in Germany - 24 scales
Front Scale
T1 Cot, T2, L, A [ B, BI, CI, S' Cos', C ] D, S Cos, ST, P
Back Scale
LL03, LL02, LL01, K, DF [ CF, K', CIF, CI, C ] D, LL1, LL2, LL3
Multiple hairlines: 360, d, A, KW, PS
Archive - Not in Collection


Faber-Castell 2/83 Log Log Duplex

REF S256
Faber-Castell 2/83 Log Log Duplex
Made in Germany - 27 scales
Front Scale (extended)
K, T1 Cot1, T2 Cot2, DF [ CF, CIF, CI, C ] D, S Cos, ST, P
Back Scale (extended)
LL03, LL02, LL01, W2 [ W2', L, C, W1' ] W1, LL1, LL2, LL3
Multiple hairlines: 360, d, A, KW, PS
Original Owner/Location: Unk/Netherlands


Faber-Castell 2/83 Log Log Duplex

ISRM 13.08.12.09


Insert (English) with Physical Properties of Metals.
Formulae for Mathematics, Mechanical, Civil and
Electrical Engineering, and Physics.
Hi resolution of the above - 600 dpi image 2.97 MB
Faber-Castell 2/83 Log Log Duplex
Made in Germany - 27 scales
Front Scale (extended)
K, T1 Cot1, T2 Cot2, DF [ CF, CIF, CI, C ] D, S Cos, ST, P
Back Scale (extended)
LL03, LL02, LL01, W2 [ W2', L, C, W1' ] W1, LL1, LL2, LL3
Multiple hairlines: 360, d, A, KW, PS
Gift of Phillip Rodley, Upper Hutt, New Zealand

2/83, 62/83
Instructions
8.41MB PDF



Phillip Rodley

Plastic clamshell storage case
Phil used this model of slide rule for one year at high school before calculators came in. He then spent 18 years working as a telephone linesman and later 18 years assembling and testing 11,000 volt circuit breakers. In his career he never needed to use a slide rule, but recently has begun enjoying relearning slide rules and logarithms. Phil is a contributor and donor of slide rules to ISRM. He is always on the hunt in New Zealand to find items to add to the ISRM galleries.


Faber-Castell 2/83N Novo-Duplex

ISRM 12.04.27.01
Faber-Castell 2/83N Novo-Duplex
Made in Germany - 31 scales
Front Scale
T1, T2, K, A, DF [ CF, B, CIF, CI, C ] D, DI, S, ST, P
Back Scale
LL03, LL02, LL01, LL00, W2 [ W2', CI, L, C, W1' ] W1, D, LL0, LL1, LL2, LL3
Multiple hairlines: 360, d, A, KW, PSy
Donated By Rod Vance, Victoria, Australia
ISRM Exhibit Placard


Faber-Castell 2/84 Mathema

REF
Faber-Castell 2/84 Mathema
Made in Germany - 22 scales
Front Scale: (exg), tan Xg, √X2-1, √X [ √x, 1/√x, 1/y, y ] Y, √(1-X2), sin Xg, (eX)
Back Scale: -0.1Ln X, -Ln X, -10Ln X [ tanh xg, 0.1 cosh xg, 0.1 sinhxg, sinh xg ] 10Ln X, Ln X, 0.1Ln X
Multiple hairlines
Archive - Rod Lovett Collection
Faber-Castell 2/84 Mathema Universal Slide Rule Instructions (English) 2.43MB. Courtesy of Gonzalo Martin, Spain - reglasdecalculo.com


Faber-Castell 2/84N Mathema Universal Slide Rule

ISRM 17.07.27.01

Faber-Castell 2/84N Mathema Universal Slide Rule
Made in Germany - ca 1971 - 24 scales
Front Scale
(exg), tan Xg, √X2-1, √X [ √x, 1/√x, 1/y, y ] Y, √(1-X2), sin Xg, (eX)
As in: L, T, √(x2-1), A [ B, BI, CI, C ] D, P, S, L
Back Scale
 10Ln X, Ln X, 0.1Ln X, Y [  y, 0.1cosh Xg, 0.1sinh Xg, sinhXg ] tanh Xg-0.1Ln X, -Ln X, -10Ln X
As in: LL0, LL1, LL2, A [B, 0.1 cosh, 0.1 sinh, sinh ] tanh, LL02, LL01, LL00
Multiple hairlines
Gift of Philip Rodley, Upper Hutt, New Zealand.
Instructions 4.1MB PDF


A.W. Faber 51/91

ISRM 12.02.19.04
A.W. Faber 51/91
Made in Germany
Front Scale: A [ B, C ] D
Back Scale: [ sin/cos, lg, tg ]
Original Owner/Location: H.Stams (1942) Germany.
Previous Owner: William M. Day USAF (1947).
Donated by Nancy Day, Kansas City, Missouri

William M. Day
William obtained this slide rule while in Germany during WWII. He was born on June 27, 1920 in Fort Dodge, Iowa. He volunteered for WWII than afterwards attended the State University of Iowa (now Univesity of Iowa) He majored in business and mathematics and graduated in 1949. He reurned to the Air Force and worked incommunications positions. He retired from military service as a Major in 1972. He worked an additional 10 years as a Credit Union Examiner for the State of Missouri. He lives in Kansas City, MO. Note: the case was repaired with match covers.


Faber-Castell 52/80 Mentor

REF S057
Faber-Castell 52/80 Mentor
Made in Germany
Front Scale
A, Df [ CF, CIF, CI, C ] D, K
Back Scale
25cm [ Instructions ] 10 inch
Multiple hairlines: 360, d-PS, KW, q
Original Owner/Location: NIB/Germany


Faber-Castell 52/81 Novo-Mentor (1970)

ISRM 14.10.09.04
Faber-Castell 52/81 Novo-Mentor dc 9-70
Made in Germany
Front Scale
A, DF(K/Z) [ CF(T), CIF, CI(P%), C(T) ] D(Z), K
Back Scale
L, T1, T2, [ S', CI, C ] D, S, ST
Multiple hairlines: 360, d, PS, KW, q
Gift Of Edward Wright, Odenton, Maryland.


Faber-Castell 152-81

REF S166
Faber-Castell 152-81
Made in Germany
Front Scale
A, DF [ CF, CIF, CI, C ] D, K
Back Scale
L, T1, T2, [ S', CI, C ] D, S, ST
Multiple hairlines: 360, d, PS, KW, q
Original Owner/Location: Unk/Peru


Faber-Castell 52/82 D-Stab (early)

REF S167
Faber-Castell 52/82 D-Stab
Made in Germany
Front Scale
L, K, A [ B, CI, C ] D, LL2, LL3
Back Scale
T1, T2, DF [ CF, CIF, C ] D, S, ST
Multiple hairlines: 360, d, q, KW, PS
Original Owner/Location: Unk/Canada


Faber-Castell Schul 52/82 D-Stab

ISRM 09.01.12.57
Faber-Castell 52/82 Schul D-Stab
Made in Germany - date code 3A
Front Scale
L, K, A [ B, CI, C ] D, LL1, LL2, LL3
Back Scale
T1, T2, DF [ CF, CIF, CI, C ] D, S, ST, P
Multiple hairlines: 360, d, A, V, KW, PS
Donated by David Hecht, Alexandria, VA


Faber-Castell 52/82 D-Stab Student Biplex

ISRM 14.10.09.09

Faber-Castell 52/82 D-Stab Student Biplex
Made in Germany
Front Scale
L, K, A [ B, BI, CI, C ] D, LL1, LL2, LL3
Back Scale
T1, T2, DF [ CF, CIF, S', C ] D, S, ST, P
Multiple hairlines: 360, d, A, V, KW, PS
Gift Of Edward Wright, Odenton, Maryland.

Instructions (11.7MB PDF)


Faber-Castell 52/82 D-Stab

REF S242
Faber-Castell 52/82 D-Stab
Made in Switzerland
Front Scale
L, K, A [ B, CI, C ] D, LL1, LL2. LL3
Back Scale
T1, T2, DF [ CF, CIF, CI, C ] D, S, ST, P
Multiple hairlines: 360, d, A, V, KW, PS
Original Owner/Location: Unk/Netherlands


A.W.Faber 55/91

REF S199
A.W.Faber 55/91
Made in Germany
Front Scale
A [ B, C ] D
Back Scale:[ sin/cos, lg, tg ]
Back blank
Original Owner/Location: Unk/Germany


Faber-Castell 57/22 Business

ISRM 14.01.10.20
Faber-Castell 57/22 Business
Made in Germany
Front Scale
10inch // Conversions, DF(P/int) [ CF(Days), CI(R%), C(Days) ] D(int), L
Back slider: [LL1, LL2, C]
Multiple hairlines:
Gift of Bill Wehrend Collection, Palo Alto, California.


Faber-Castell 57/86 Columbus

ISRM 09.01.12.58
Faber-Castell 57/86 Columbus
Made in Germany - date code 573 (May 1973), 1962 copyright
Front Scale
27 cm // A [ B, C ] D
Back: Instructions on basic math
Multiple hairlines: S, KW, HP
Donated by David Hecht, Alexandria, VA


Faber-Castell 57/87 Rietz

ISRM 09.01.12.59
Faber-Castell 57/87 Reitz
Made in Germany - date code 157 (Jan 1957)
Front Scale
27 cm // K, A [ B, CI, C ] D, L
Back slider: [S, ST, T]
Multiple hairlines: S, KW, HP
Donated by David Hecht, Alexandria, VA


Faber-Castell 57/87 Rietz Schul-Rechenstab

ISRM 09.01.12.60
Faber-Castell 57/87 Reitz Schul-Rechenstab
Made in Germany - date code 1163 (Nov 1963)
Front Scale
27 cm // K, A [ B, CI, C ] D, L
Back slider: [S, ST, T]
Multiple hairlines: S, KW, HP
Donated by David Hecht, Alexandria, VA


Faber-Castell 57/87 Rietz Schul-Rechenstab

ISRM 09.01.12.61
Faber-Castell 57/87 Reitz Schul-Rechenstab
Made in Germany - date code 965 (Sep 1965)
Front Scale
27 cm // K, A [ B, CI, C ] D, L
Back slider: [S, ST, T]
Multiple hairlines: S, KW, HP
Donated by David Hecht, Alexandria, VA


Faber-Castell 57/87 Rietz

REF S004
Faber-Castell 57/87 Rietz
Made in Germany
Front Scale
10inch // K, A [ B, CI, C ] D, L
Back slider: [S, ST, T]
Multiple hairlines: S, KW, HP
Original Owner/Location: NIB/Germany


Faber-Castell 157/87 Rietz

ISRM 09.01.12.62
Faber-Castell 157/87 Rietz
Made in Germany - date code 3A (1952), Injection Molded Geroplast
Front Scale
10inch // K, A [ B, CI, C ] D, L
Back slider: [S, ST, T]
Multiple hairlines: S, KW, HP
Original owner: Dick Cornelius
Donated by David Hecht, Alexandria, VA


Faber-Castell 57/88

REF S005
Faber-Castell 57/88 D-Stab
Made in Germany
Front Scale
27cm, K, A [ B, L, CI, C ] D, S, ST, T1, T2
Multiple hairlines: S, KW, HP
Original Owner/Location: NIB/Germany


Faber-Castell 2/82 Biplex
ISRM 12.06.24.03
Faber-Castell 2/82 Biplex dcUnreadable
Made in Germany - 24 scales (early scale set)
Front Scale
12.5cm, T1, T2, A [ B, BI, CI, C ] D, P, S, 5inch
Back Scale
LL03, LL02, LL01, K [ K', L, ST, CF ] DF, LL1, LL2, LL3
Multiple hairlines: 360, d, A, KW, PS
Original owner: David Herrera (written inside case)
Donated by Anonymous collector and daughter.
The collector, who prefers to remain anonymous, obtained a B.S. degree in Physics from Taiwan's National Tsing Hua University in 1971. His love for computation has encouraged him to build a collection of slide rules, HP and TI calculators, as well as abaci, many displayed at ISRM.


Faber-Castell 62/82 Biplex

REF P030
Faber-Castell 62/82 Biplex
Made in Germany - 24 scales (Later scale set) with green tinted C & D scales
Front Scale
L, T1, T2, A [ B, BI, CI, C ] D, S Cos, ST, P
Back Scale
LL03, LL02, LL01, K [ K', C, CIF, CF ] DF, LL1, LL2, LL3
Multiple hairlines: 360, d, A, KW, PS
Original Owner/Location: NIB/Germany


Faber-Castell 62/83 Biplex

REF
Faber-Castell 62/83 Biplex
Made in Germany - 24 scales
Front Scale
K, T1, T2, DF [ CF, CIF, CI, C ] D, ST, S Cos, P
Back Scale
LL03, LL02, LL01, W2 [ W2', L, C, W1' ] W1, LL1, LL2, LL3
Multiple hairlines: 360, d, A, KW, PS
Archive - Ebay picture


Faber-Castell 62/83N Novo-Duplex

REF
Faber-Castell 62/83N Novo-Duplex
Made in Germany - 31 scales
Front Scale
T1, T2, K, A, DF [ CF, B, CIF, CI, C ] D, DI, S, ST, P
Back Scale
LL03, LL02, LL01, LL00, W2 [ W2', CI, L, C, W1' ] W1, D, LL0, LL1, LL2, LL3
Multiple hairlines: 360, d, A, KW, PS
Archive - Not in Collection


Faber-Castell 63/39 M-A-N

REF P068
Faber-Castell 63/39 M-A-N
Made in Germany
Front Scale
14cm // A [ B, C ] D
Back slider: Blank
Back Adv: M-A-N
Original Owner/Location: Unk/Germany


Faber-Castell 63/39 WDFG

REF P033
Faber-Castell 63/39 WDFG
Made in Germany
Front Scale
14cm // A [ B, C ] D
Back slider: Blank
Back Adv: Westfalia-Dinnendahl-Groppel
Original Owner/Location: Unk/Germany


Faber 163/81 Novo Mentor

REF P108
Faber 163/81 Novo Mentor
Made in Germany - 17 scales
Front Scale
A, (K/Z)DF [ (T)CF, CIF, (P%)CI, (T)C ] (Z)D, K
Back Scale
L, T1, T2 [ S', CI, C ] D, S, ST
Multiple hairlines: 360, d, Theta, KW, PS
Original Owner/Location: Unk/Germany


Faber-Castell 63/82 Biplex

REF
Faber-Castell 63/82 Biplex
Made in Germany - 24 scales
Front Scale
L, T1, T2, A [ B, BI, CI, C ] D, S, ST, P
Back Scale
LL03, LL02, LL01, K [ K', C, CIF, CF ] DF, LL1, LL2, LL3
Multiple hairlines: 360, d, A, KW, PS
Archive - Not in Collection


Faber-Castell 63/83 Novo-Biplex

REF
Faber-Castell 63/83 Novo-Biplex
Made in Germany - 27 scales
Front Scale
K, T1, T2, DF [ CF, CIF, CI, C ] D, S, ST, P
Back Scale
LL03, LL02, LL01, W2 [ W2', L, C, W1' ] W1, LL1, LL2, LL3
Multiple hairlines: 360, d, q, KW, PS
Archive - Not in Collection


Faber-Castell 63/91

REF P038
Faber-Castell 63/91
Made in Germany
Front Scale
14cm // A [ B, C ] D
Back slider: [ Sin, Lg, Tg ]
Back Adv: G, Ch. Bodicker
Original Owner/Location: Unk/Germany


Faber-Castell 63/98R Elektro with Addiator

REF P154
Faber-Castell 63/98R Elektro with Addiator Hybrid
Made in Germany
Front Scale
14cm // LL2, A(KW) [ B(PS), CI, C ] D, LL3 \\ 5.5in
Back scale: [ Sin, Lg, Tg ]
Well scale: Dynamo/Motor n=%, Volt
Original Owner/Location: M.Bachmann/Germany


Faber-Castell 67/22 Disponent

REF P035
Faber-Castell 67/22 Disponent
Made in Germany
Front Scale
14cm // +/-%, DF(Cap./Int) [ CF(Dias), CI(p%), C(Dias) ] D (Int.)
Back slider: [Sh/d, PoundSterling]
Original Owner/Location: Unk/Germany


Faber-Castell 67/39 Rietz - 14mm (1952)

ISRM 09.01.12.55
Faber-Castell 67/39 Rietz - 14mm
Made in Germany - Date Code 52-10 (Oct 1952)
Front Scale
14mm // A [ B, C ] D
Back: Blank
Well Advertisement: Linde
Donated by David Hecht, Alexandria, Virginia


Faber-Castell 67/39 Rietz - 5in (1968)

ISRM 09.01.12.56
Faber-Castell 67/39 Rietz - 5in
Made in Germany - Date Code 1168 (Nov 1968)
Front Scale
5in // A [ B, C ] D
Back: Blank
Donated by David Hecht, Alexandria, Virginia
Instructions 6.78MB PDF


Faber-Castell 67/54 B Darmstadt

ISRM 13.08.12.08
Faber-Castell 67/54 B Darmstadt
Made in Germany
Front Scale (extended scale)
14cm // L, K, A [ B, CI, C ] D, P, S, T
Back Slide: [ LL1, Ll2, LL3 ]
Cursor: Multiple hairlines
Back: 5inch rule
Donated by Phillip Rodley, Upper Hutt, New Zealand


Faber-Castell 67/54 B Darmstadt

REF P029
Faber-Castell 67/54 B Darmstadt
Made in Germany - Note: the K,A,B,C,D scales are gold color
Front Scale
14cm // L, K, A [ B, CI, C ] D, P, S, T
Back Slide: [ LL1, Ll2, LL3 ]
Cursor: Multiple hairlines
Back: 5inch rule Adv: BASF
Original Owner/Location: Unk/England


Faber-Castell 67/54 RB Darmstadt/Addiator

ISRM 07.02.12.01

Faber-Castell 67/54 RB Darmstadt/Addiator
Made in Germany - Slide rule fron. addiator back
Front Scale
14cm // L, K, A [ B, CI, C ] D, P, S, T
Back Slide: [ LL1, Ll2, LL3 ]
Cursor: Multiple hairlines
Note: The slide was found accessible by a puppy (see teeth marks)
Donation of Russell Fox, Anchorage, Alaska


Faber-Castell 67/87 Rietz (1965)

ISRM 09.01.12.54
Faber-Castell 67/87 Rietz
Made in Germany - Date Code 865 (Aug 1965)
Front Scale
14mm // K, A [ B, CI, C ] D, L
Back slider: [S, ST, T]
Multiple hairlines
Back Advertisement: Barmag.
Donated by David Hecht, Alexandria, Virginia


Faber-Castell 67/87 Rietz

ISRM 13.06.28.03


Pocket Sleeve

Instructions 6.78MB PDF


Jim Rodgers

Faber-Castell 67/87 Rietz
Made in Germany - Date Code 765 (July 1965)
Front Scale
14mm // K, A [ B, CI, C ] D, L
Back slide: [S, ST, T]
Multiple hairlines
Gift Of Susan Jackson, Boulder, Colorado, daughter of Jim Rodgers
Jim Rodgers (1929-2012) used this slide rule (and others found within ISRM) during his career. He was a Naval Aviator and had training at the the Nuclear Weapons Training Center - Atlantic (c1968). He later resided in Boulder, Colorado. He was married to Ceil Rodgers for 63 years and had four children, Jim, Susan, Cathy and Stephen, and eight grandchildren. An avid reader, progressive thinker, political junkie, problem solver and perpetual optimist, Jim was loved and admired by everyone who knew him. Jim donated his body to science.


Faber-Castell 67/87b Rietz with Addiator

ISRM 13.10.07.06
Faber-Castell 67/87b Rietz
Made in Germany - Date Code 865 (Aug 1965)
Front Scale
14mm // L, K, A [ B, CI, C ] D, ST, T
Back slide: blank
Multiple hairlines
Back Addiator
Note: Stylus for addiator kept in zippered hardcase.


Faber-Castell 167/98b Elektro

REF P159
Faber-Castell 167/98b Elektro
Made in Germany
Front Scale
14cm // LL2, A [ B, CI, C ] D, LL3, Dynamo/Motor%, Volt
Back slider: [S, L, T] Multiple hairlines
Original Owner/Location: Unk/Germany


Faber-Castell 8/10 12.3cm dia

REF
Faber-Castell 8/10 12.3cm Dia
Made in Germany
Front Scale
K, A, L, D ( C, CI, B, T1, T2, S, S )
Back: Instructions on Use
Multi-lined Cursor: KW, (3)PS, (2)q
Archive - Rod Lovett Collection



Faber Castell 989 Complex Slide Rule Calculator
(Komplex-Rechenplatte)

ISRM 12.03.21.01
Faber Castell 989 Complex Slide Rule Calculator (Komplex-Rechenplatte)
Made in Germany - This basically an integrated slide rule with 3 degrees of freedom and a nomograph.

Summary of Function By Dieter von Jezierski and Rodger Shepherd

Donated by Henry (Hank) Benoit, Kingston, Ontario, Canada

Henry Benoit (BSEE 1968, MSc 1970) had a hands-on biomedical engineering career in OB/GYN research at University of Toronto and clinical engineering at University of Ottawa Heart Institute. His graduate work focussed on electroanesthesia and electrosleep. During the 70s he applied an early Fairchild charge-coupled device to observation of internal organs and designed portable instrumentation based on the RCA COSMAC computer chip set and the FORTH language. Later he contributed to excimer laser applications in cardiac ablation surgery and integration of electronic technologies into clinical settings.
Hanks comment on this apparatus: "The 989 is a beautiful piece (to an engineer). My wife never saw it in that light. It was purchased for coursework in electromagnetic fields. It offered the contiuously-variable feature inherent in analog devices. Once the coursework was done I no longer found applications and electronic gadgets began to provide convenient complex functions anyway." See Hank's other personal slide rules, the Aristo 0970 Multilog and 870 (pocket) Multilog in the Aristo Gallery.

Instructions
German
6.07Mb PDF


Instructions
English
8.06Mb PDF

Alternate Translation By
Dieter von Jezierski
and Rodger Shepherd
English
7.08Mb PDF


REF Faber-Castell TR1 Electronic Calculator SR
Faber-Castell TR1 Electronic Calculator SR Hybrid
Made in Germany
Front Electronic Calculator
+, -, /, *, %, 1/x, x2, M
Back Conventional Slide Rule
LL03, LL02, LL01, K, A [ B, BI, CI, C ] D, L, LL1, LL2, LL3
Multi-lined Cursor
Archive - Faber-Castell.de
Large Large
Scans of brochure donated by Dieter von Jezierski, Germany


REF Faber-Castell TR2
Electronic Calculator SR

ISRM 12.09.24.01


Faber-Castell.de
archive photo

Faber-Castell TR2 Electronic Calculator SR Hybrid
Made in Germany - sn025120910
Front Electronic Calculator
+, -, /, *, X-Y, MS, MR, M1, M+, Pi, SQR, %, +/-, (, ), SinX, CosX, TanX. lnX, logX, etc
Back Conventional Slide Rule
Scale: LL03, LL02, LL01, K, A [ B, BI, CI, C ] D, L, LL1, LL2, LL3
Slide (reversible): [ T1 Cot, ST, S Cos, T, P, C ]
Multi-lined Cursor
Note: This scale set was only found on the TRs to compliment the calculator functions.


REF Faber-Castell TR3 Electronic Calculator SR
Faber-Castell TR3 Electronic Calculator SR Hybrid
Made in Germany
Front Electronic Calculator
+, -, /, *, X-Y, MS, MR, M1, M+, SQR, %, +/-, (, ).
Back Conventional Slide Rule
LL03, LL02, LL01, K, A [ B, BI, CI, C ] D, L, LL1, LL2, LL3
Multi-lined Cursor
Archive - Faber-Castell.de


Instructions (German & English) 2.66MB
Faber-Castell Verlag Chemie (Chemical slide rule)
ISRM 12.09.15.01
Faber-Castell Verlag Chemie (Chemical slide rule)
Made in Germany by Faber-Castell for Verlag Chemie - Weinheim
Front Scales
K, T1 Cot, T2 Cot, DF [ CF, L, CI, C ] D, LL3, LL03, LL02
Back Scales
C, OCH3, N(Si/2) O(S/2), F Br, H MG [ B %, 1) CI C ] D, B, P, Cl J
Multi-lined Cursor
Instructions courtesy of Gonzalo Martin, Spain - reglasdecalculo.com

ISRM dating guide

1966 Catalog and pages on scales of slide rule models and construction description.
Copyright © 2003-2017 International Slide Rule Museum
